Why does Inovance Inverter show overcurrent at constant speed?
An Inovance Inverter displaying overcurrent at a constant speed may be caused by a grounded or short-circuited output circuit, a sudden load added during operation, or the AC drive model being of too small a power class. To address this: * Replace external faults. * Remove the added load. * Select an AC drive of a higher power class.
What to do if Inovance MD280NT3.7GB Inverter shows overcurrent during deceleration?
If your Inovance Inverter indicates overcurrent during deceleration, it could be due to a grounded or short-circuited output circuit, a deceleration time that is too short, low voltage, a sudden load added during deceleration, or the absence of a braking unit and braking resistor. Consider the following solutions: * Replace external faults. * Increase the deceleration time. * Adjust the voltage to the normal range. * Remove the added load. * Install the braking unit and braking resistor.
General| Model | MD280NT3.7GB |
|---|---|
| Rated Power | 3.7kW |
| Protection Level | IP20 |
| Cooling Method | Forced air cooling |
| Type | Inverter |
| Output Voltage | 3-phase 0 - Input Voltage |
| Control Mode | V/F control |
| Communication Interface | RS485 |
Details safety notices, grades (DANGER, WARNING), and precautions for installation and use.
Describes the components and indicators of the AC drive's operation panel, with and without a potentiometer.
Explains the three-level menu structure for navigating and modifying function codes on the operation panel.
Outlines methods for starting and stopping the AC drive using operation panel, terminals, or communication.
Covers setting the running frequency using main and auxiliary sources, including manual, analog, and digital inputs.
Guides on setting motor parameters and performing static auto-tuning for optimal performance.
Covers fundamental settings like command source, frequency sources, and protection.
Details motor-specific settings, V/F curves, auto-tuning, and protection parameters.
Explains configuration of digital and analog input terminals for control and sensing.
Details configuration of output terminals for status indication, alarms, and pulse outputs.
Parameters for managing drive start, stop, acceleration, deceleration, and braking modes.
Covers functions like JOG running, jump frequency, dormant/wakeup modes, and protection settings.
Details parameters for PID closed-loop control, including gains, limits, and action settings.
Covers functions for swing frequency, fixed length control, and counting operations.
Covers multi-reference settings and parameters for the built-in Simple PLC functionality.
Configures serial communication settings for host computer interaction.
Parameters for motor overload, overvoltage, overcurrent protection, and ride-through functions.
Provides a table of common faults, their possible causes, and recommended solutions for the AC drive.
Lists common AC drive faults, their causes, and troubleshooting steps.
