Inovance MD290 Series User Manual

1. Product Information
- 13 -
1
1.3 Ratings
Table 1-1 Ratings of MD290T18.5G/22P to MD290T160G/200P
Voltage Class 380 to 480 VAC
MD290TxxG/xxP(B
Ǐ
1
ǐ
)(-INT) 18.5G/22P 22G/30P 30G/37P 37G/45P 45G/55P 55G/75P 75G/90P
Drive Input
Rated Input Voltage Three-phase 380 to 480 V, -15% to +10%
Rated Input
Current, [A]
G type 49.5 59 57 69 89 106 139
P type 59 65.8 71 86 111 143 167
Rated Input Frequency 50/60 Hz, ±5%
Power
Capacity,
[kVA]
G type 45 54 52 63 81 97 127
P type 54 60 65 79 102 131 153
Drive Output
Applicable
Motor
G type [kW] 18.5 22 30 37 45 55 75
G type [HP] 25 30 40 50 60 75 100
P type [kW] 22 30 37 45 55 75 90
P type [HP] 30 40 50 60 75 100 120
Output
Current, [A]
G type 37 45 60 75 91 112 150
P type 45 60 75 91 112 150 176
Default Carrier
Frequency, [kHz]
6665543
Overload Capacity G type: 150% for 60 Sec,
P type: 110% for 60 Sec
Max. Output Voltage Three-phase 380 to 480 VAC (proportional to input voltage)
Max. Output Frequency 500 Hz
Braking Resistor
Recommended Power,
[kW]
44.56791115
Recommended
5HVLVWDQFH0LQ>@
24 24 19.2 14.8 12.8 9.6 6.8
Thermal Design
Thermal design power,
[kW]
0.478 0.551 0.694 0.815 1.01 1.21 1.57
$LUÀRZ>&)0@ 51.9 57.4 118.5 118.5 122.2 122.2 218.6
Enclosure IP20
Note
Ǐ
1
ǐ
: "B" denotes build-in brake function for MD290T18.5G/22P to MD290T75G/90P.
