Inovance MD290 Series User Manual

6. Description of Parameters
- 142 -
6
The function parameters related acceleration/deceleration time are as follows:
Function Code Parameter Name Setting Range Default
F0-17
Acceleration time 1 0.00 to 650.00s (F0-19 = 2)
0.0 to 6500.0s (F0-19 = 1)
0 to 65000s (F0-19 = 0)
Model dependent
F0-18
Deceleration time 1 0.00 to 650.00s (F0-19 = 2)
0.0 to 6500.0s (F0-19 = 1)
0 to 65000s (F0-19 = 0)
Model dependent
F8-03
Acceleration time 2 0.0s to 6500.0s Model dependent
F8-04
Deceleration time 2 0.0s to 6500.0s Model dependent
F8-05
Acceleration time 3 0.0s to 6500.0s Model dependent
F8-06
Deceleration time 3 0.0s to 6500.0s Model dependent
F8-07
Acceleration time 4 0.0s to 6500.0s Model dependent
F8-08
Deceleration time 4 0.0s to 6500.0s Model dependent
F0-19
Acceleration/
Deceleration time unit
0:1s
1: 0.1s
2: 0.01s
1
F0-25
Acceleration/
Deceleration time
base frequency
0: Maximum frequency (F0-10)
1: Frequency reference
2: 100 Hz
0
F6-07
Acceleration/
Deceleration mode
0: Linear acceleration/deceleration
1: Static S-curve acceleration/
deceleration
2: Dynamic S-curve acceleration/
deceleration
0
F6-08
Time proportion of
S-curve start segment
0.0% to (100.0% – F6-09) 30.0%
F6-09
Time proportion of
S-curve end segment
0.0% to (100.0% – F6-08) 30.0%
F6-07 sets acceleration/deceleration mode.
Ɣ
F6-07 = 0: Linear acceleration/deceleration
Output frequency increases or decreases linearly. The drive provides four groups of
acceleration/deceleration time, selected via F4-00 to F4-08.
Ɣ
F6-07 = 1: Static S-curve acceleration/deceleration
Output frequency increases or decreases along S curve on the condition that target
IUHTXHQF\LV¿[HG7KLVPRGHLVDSSOLHGWRDSSOLFDWLRQVZKHUHVRIWVWDUWRUVWRSLVUHTXLUHG
such as elevator and conveyor belt.
Ɣ
F6-07 = 2: Dynamic S-curve acceleration/deceleration
Output frequency increases or decreases along S curve on the condition that target
frequency is changing at real time. This mode is applicable to applications requiring supreme
riding comfort and fast response.
F6-08 and F6-09 define time proportion of start segment and end segment of S-curve
DFFHOHUDWLRQGHFHOHUDWLRQUHVSHFWLYHO\7KH\PXVWVDWLVI\))
