Inovance MD290T45G/55P User Manual

1. Product Information
- 14 -
1
Table 1-2 Ratings of MD290T90G/110P to MD290T160G/200P
Voltage Class 380 to 480 VAC
MD290TxxG/xxP(-INT) 90G/110P 110G/132P 132G/160P 160G/200P
Drive Input
Rated Input Voltage Three-phase 380 to 480 V, -15% to +10%
Rated Input
Current, [A]
G type 164 196 240 287
P type 198 239 295 359
Rated Input Frequency 50/60 Hz, ±5%
Power
Capacity, [kVA]
G type 150 179 220 263
P type 181 219 270 328
Drive Output
Applicable
Motor
G type [kW] 90 110 132 160
G type [HP] 120 150 180 220
P type [kW] 110 132 160 200
P type [HP] 150 180 220 267
Output
Current, [A]
G type 176 210 253 304
P type 210 253 304 377
Default Carrier Frequency, [kHz] 3 3 3 3
Overload Capacity G type: 150% for 60 Sec,
P type: 110% for 60 Sec
Max. Output Voltage Three-phase 380 to 480 VAC (proportional to input voltage)
Max. Output Frequency 500 Hz
Braking
R e s i s t o r
Recommended Power, [kW] 18 22 26 32
Recommended Resistance, Min.
>@
5.3 5.3 3.5 3.5
Thermal Design
Thermal design power, [kW] 1.81 2.14 2.85 3.56
$LUÀRZ>&)0@ 287.2 342.2 547 627
Enclosure IP20
