Inovance MD290T45G/55P User Manual

1. Product Information
- 15 -
1
Table 1-3 Ratings of MD290T200G to MD290T280G and MD290T220P to MD290T315P
Voltage Class 380 to 480 VAC
Model: MD290Txxxx(-L)**(-INT) 200G 220P 220G 250P 250G 280P 280G 315P
Drive Input
Rated Input Voltage Three-phase 380 to 480V, -15% to +10%
Rated Input Current, [A] 365 410 410 456 441 507 495 559
Power Capacity, [kVA] 334 375 375 417 404 464 453 511
Rated input frequency 50/60 Hz, ±5%
Drive Output
Applicable Motor, [kW] 200 220 220 250 250 280 280 315
Output Current, [A] 377 426 426 465 465 520 520 585
Default carrier frequency, [kHz] 3 3 3 3 3 3 3 3
Overload Capacity G type: 150% for 60 Sec
P type: 110% for 60 Sec
Max. output voltage Three-phase 380 to 480 VAC (proportional to input voltage)
Max. output frequency 500 Hz
Braking
Resistor
Recommended Power, [kW] 38 38 42 42 48 48 54 54
Recommended Resistance,
PLQ>@
2.9 2.9 2.7 2.7 2.3 2.3 2.1 2.1
Thermal
Design
Thermal design power, [kW] 4.15 4.55 5.06 5.33 5.69 6.31 6.91 7.54
$LUÀRZ>&)0@ 638.4 722.5 789.4 882 645 860 860 860
Enclosure IP00
Table 1-4 Ratings of MD290T315G to MD290T450G and MD290T355P to MD290T500P
Voltage Class 380 to 480 VAC
Model: MD290Txxxx(-L)**(-INT) 315G 355P 355G 400P 400G 450P 450G 500P
Drive Input
Rated Input Voltage Three-phase 380 to 480V, -15% to +10%
Rated Input Current [A] 565 624 617 708 687 782 782 840
Power Capacity, [kVA] 517 571 565 647 629 715 716 768
Rated input frequency 50/60 Hz, ±5%
Drive Output
Applicable Motor, [kW] 315 355 355 400 400 450 450 500
Output Current, [A] 585 650 650 725 725 820 820 880
Default carrier frequency, [kHz] 3 3 3 3 3 3 3 3
Overload Capacity G type: 150% for 60 Sec (For MD290T450G, the capacity is 130%.)
P type: 110% for 60 Sec
Max. output voltage Three-phase 380 to 480 VAC (proportional to input voltage)
Max. output frequency 500 Hz
Braking
Resistor
Recommended Power, [kW] 54 60 69 69 78 78 87 87
Recommended Resistance,
PLQ>@
2.1 1.9 1.7 1.7 1.5 1.5 1.3 1.3
Thermal
Design
Thermal design power, [kW] 4.15 4.55 5.06 5.33 5.69 6.31 6.91 7.54
$LUÀRZ>&)0@ 638.4 722.5 789.4 882 645 860 860 860
Enclosure IP00
Note

: Model name with "L" in Table 1-3 and Table 1-4 means with the built-in AC output reactor
and cabinet.
