Inovance MD290T45G/55P User Manual

6. Description of Parameters
- 167 -
6
Related function parameters are as follows:
Function Code Parameter Name Setting Range Default
Fb-00
Wobble setting mode 0: Relative to the frequency reference
1: Relative to the max. frequency
0
This function parameter selects base value of wobble amplitude.
Function Code Parameter Name Setting Range Default
Fb-01
Wobble amplitude 0.0% to 100.0% 0.0%
Fb-02
Wobble step 0.0% to 50.0% 0.0%
Fb-01 and Fb-02: These function parameters set wobble amplitude and wobble step.
Ɣ When Fb-00 = 0, Aw (wobble amplitude) = F0-07 (Frequency source superposition selection)
x Fb-01.
Ɣ When Fb-00 = 1, Aw (wobble amplitude) = F0-10 (Max. frequency) x Fb-01.
Wobble step frequency = Aw (wobble amplitude) x Fb-02 (Wobble step). The wobble running
frequency must be within frequency upper limit and frequency lower limit.
Function Code Parameter Name Setting Range Default
Fb-03
Wobble cycle 0.0s to 3000.0s 10.0s
Fb-04
Triangular wave rising
WLPHFRHI¿FLHQW
0.0% to 100.0% 50.0%
)E,WVSHFL¿HVWLPHRIDFRPSOHWHZREEOHF\FOH
Fb-04: It is percentage of triangular wave rising time to Fb-03 (Wobble cycle).
Ɣ
Triangular wave rising time = Fb-03 (Wobble cycle) x FB-04 (Triangular wave rising time
FRHI¿FLHQWXQLWV
Ɣ
Triangular wave falling time = Fb-03 (Wobble cycle) x (1 - Fb-04 Triangular wave rising time
FRHI¿FLHQWXQLWV
