6. Description of Parameters
- 180 -
6
Value Function Description
33 External fault NC input
Once terminal set for this function becomes on, the AC drive detects
ERR15 and stops.
34 Frequency
PRGL¿FDWLRQHQDEOHG
When terminal set for this function becomes on, the AC drive responds to
IUHTXHQF\PRGL¿FDWLRQ
35 PID operation
direction reverse
When terminal set for this function becomes on, PID operation direction is
reversed to direction set in FA-03.
36 External stop 1
In operation panel control, the terminal set for this function can be used to
stop the AC drive, equivalent to function of the STOP key on the operation
panel.
37 Command source
switchover 2
Terminal set for this function is used to perform switchover between
terminal control and communication control. If command source is
terminal control, the AC drive switches over to communication control
after the terminal becomes ON.
38 PID integral disabled
When terminal set for this function becomes on, the integral function
becomes disabled. However, the proportional and differentiation functions
are still effective.
39 Switchover between
main frequency
reference and preset
frequency
When terminal set for this function becomes on, the frequency reference
is replaced by preset frequency set in F0-08.
40 Switchover between
auxiliary frequency
reference and preset
frequency
When terminal set for this function becomes on, frequency reference is
replaced by preset frequency set in F0-08.
41 Motor selection
Switchover between motor 1 and motor 2 can be implemented through
two state combinations of terminal set for this function.
42 Reserved
-
43 PID parameter
switchover
If PID parameters switchover is done via DI terminal (FA-18 = 1), PID
parameters are FA-05 to FA-07 when terminal set for this function
becomes off; PID parameters are FA-15 to FA-17 when terminal set for
this function becomes on.
44 8VHUGH¿QHGIDXOW
If terminals selecting these two functions become on, the AC drive detects
Err27 and Err28 respectively, and performs fault protection based on
setting of F9-49.
45 8VHUGH¿QHGIDXOW
47 Emergency stop (ES)
When the ES terminal becomes on, the AC drive decelerates based on
the setting of F8-55 (deceleration time for emergency stop). If F8-55 =
0 in V/F control, the AC drive decelerates based on the setting of F0-19
(Acceleration/Deceleration time unit).
The AC drive will not operate when the ES terminal is ON even if the
terminal receiving RUN command is ON. In this case, to make the AC
drive operate again, turn off the terminal receiving RUN command and
then turn it on.
48 External stop 2
This function enables the AC drive to decelerate to stop in any control
mode (operation panel, terminal or communication). In this case, the
deceleration time is deceleration time 4.
49 Deceleration DC
injection braking
When terminal set for this function becomes on, the AC drive decelerates
to DC injection braking 2 frequency threshold and then switches over to
DC injection braking state.
