1. Product Information
- 19 -
1
Item Description
Display and
operating panel
LED display The LED display shows parameter values.
Key locking and function
selection
Ɣ
Keys on the control panel can be locked or
partially locked electronically to prevent accidental
operation.
Ɣ
The range of some functions can be limited to a
permitted range to prevent incorrect settings.
Protections Phase loss protection
Ɣ
Input phase loss protection
Ɣ
Output phase loss protection
Instantaneous overcurrent
protection
Stop when output current exceeds 250% of rated output
current
Overvoltage protection Stop when the main circuit DC voltage is above 820 V
Undervoltage protection Stop when the main circuit DC voltage is below 350 V
Overheat protection Protection triggered when the inverter bridge gets
overheated.
Overload protection Stop after running at 150% of rated current for 60
seconds.
Overcurrent protection Stop when output current exceeds 250% of rated
current of the AC drive
Braking protection
Ɣ
Braking unit overload protection
Ɣ
Braking resistor short-circuit protection
Short-circuit protection
Ɣ
Output inter-phase short-circuit protection
Ɣ
Output short-circuit to ground protection
Environment Installation location Install the AC Drive where it is indoors and protected
from direct sunlight, dust, corrosive or combustible
gases, oil smoke, vapour, ingress from water or any
other liquid, and salt.
Altitude Below 1000 m
If the altitude is above 1000 m, de-rate the drive
according to
1
.
5
D
e
-
r
a
t
i
n
g
.
Max. 3000 m for LVD directive requirement.
Ambient temperature –10°C to +40°C
If the ambient temperature is in the range of 40°C to
50°C, de-rate the drive according to
1
.
5
D
e
-
r
a
t
i
n
g
.
Humidity Less than 95% RH non-condensing.
Pollution level PD2
Overvoltage category OVC III
Vibration Less than 5.9 m/s² (0.6 g).
Storage temperature –20°C to +60°C
