1. Product Information
- 18 -
1
Item Description
RUN Command source Allows different methods of switching between command
sources:
Ɣ
Operating panel (keypad & display)
Ɣ
Terminal I/O control
Ɣ
Serial communication
Main frequency reference
setting channel
Supports up to 10 frequency reference setting channels
and allows different methods of switching between
frequency reference setting channels:
Ɣ
Digital setting
Ɣ
Analog voltage reference
Ɣ
Analog current reference
Ɣ
Pulse reference
Ɣ
Communication reference
Auxiliary frequency
reference setting channel
Supports up to 10 auxiliary frequency sources, and allows
¿QHWXQLQJRIWKHDX[LOLDU\IUHTXHQF\DQGPDLQDX[LOLDU\
calculation.
Input terminals Standard:
Ɣ
5 digital input (DI) terminals, one of which supports up
to 100 kHz high-speed pulse inputs.
Ɣ
2 analog input (AI) terminals, one of which supports
only 0 to10 V input, and the other supports 0 to 10 V
and 4 to 20 mA current input.
Expanded capacity:
Ɣ
5 digital input (DI) terminals.
Ɣ
1 AI terminal that supports –10 to 10 V voltage input
and PT100/PT1000 motor temperature sensor inputs.
Output terminals Standard
Ɣ
1 high-speed pulse output terminal (open-collector) for
a square-wave signal output in the frequency range 0
to 100 kHz
Ɣ
1 digital output (DO) terminal
Ɣ
1 relay output terminal
Ɣ
1 analog output (AO) terminal that supports either a
current output in the range 0 to 20 mA or a voltage
output in the range 0 to 10 V.
Expanded capacity:
Ɣ
1 extra DO terminal
Ɣ
1 extra relay output terminal
Ɣ
1 extra AO terminal that supports either a current
output in the range 0 to 20 mA or a voltage output in
the range 0 to 10 V.
