dv/dt Reactor Installation
Connect a dv/dt reactor on the output side to reduce large dv/dt, protecting the motor
winding from insulation breakdown, lowering motor temperature and extending the motor
service life and meanwhile reduce interference on surrounding devices.
Ɣ
Selection of the dv/dt reactor (Schaffner)
AC Drive Model dv/dt Reactor
Model
Rated
Current at
40°C (A)
Rated
Motor
Power
(kW)
Rated
Inducance
(mH)
Power
Consum-
ption (W)
I/O Terminal
Selection
Total
(kg)
MD290T18.5GB/22P RWK 305-45-KL 45 18.5 0.131 60 KL - - 6.1
MD290T22GB/30P RWK 305-45-KL 45 22 0.131 60 KL - - 6.1
MD290T30GB/37P RWK 305-60-KL 60 30 0.098 65 KL - - 6.1
MD290T37GB/45P RWK 305-72-KL 72 37 0.082 70 KL - - 6.1
MD290T45GB/55P
RWK 305-90-KL 90 45 0.065 75 KL - - 7.4
MD290T55GB/75P RWK 305-110-KL 110 55 0.053 90 KL - - 8.2
MD290T75GB/90P RWK 305-156-KS 156 75 0.038 120 - KS - 10.7
MD290T90G/110P RWK 305-182-KS 182 90 0.032 140 - KS - 16
MD290T110G/132P RWK 305-230-KS 230 110 0.026 180 - KS - 22
MD290T132G/160P RWK 305-280-KS 280 132 0.021 220 - KS - 29
MD290T160G/200P RWK 305-330-KS 330 160 0.018 240 - KS - 32
MD290T200G(-L)
RWK 305-400-S 400 200 0.015 330 - - S 34MD290T220P(-L)
MD290T250P(-L)
MD290T220G(-L)
RWK 305-500-S 500 220 0.012 340 - - S 35
MD290T280P(-L)
MD290T250G(-L)
RWK 305-500-S 500 250 0.012 340 - - S 35
MD290T315P(-L)
MD290T280G(-L)
RWK 305-600-S 600 280 0.01 380 - - S 37
MD290T355P(-L)
MD290T315G(-L)
RWK 305-600-S 600 315 0.01 380 - - S 37
MD290T400P(-L)
MD290T355G(-L)
RWK 305-680-S 680 355 0.009 410 - - S 38
MD290T450P(-L)
MD290T400G(-L)
RWK 305-790-S 790 400 0.007 590 - - S 43
MD290T500P(-L)
MD290T450G(-L) RWK 305-910-S 910 450 0.006 740 - - S 49
