2. Mechanical Installation
- 34 -
2
7DEOH6SHFL¿FDWLRQRIGLUHFWGLVFKDUJLQJFDELQHW
MD290 Model Quantity of Fans Total Air Volume
(CFM)
Effective Area of Cabinet
Top Air Inlet (mm
2
)
Effective Area of Cabinet
Top Air Outlet (mm
2
)
MD290T132G 2 541 31809 50894
MD290T160P
MD290T160G 2 620 31809 50894
MD290T200P
MD290T200G(-L) 2 586 31809 50894
MD290T220P(-L)
MD290T250P(-L)
MD290T220G(-L) 2 722 31809 50894
MD290T280P(-L)
MD290T250G(-L) 3 789 47713 76341
MD290T315P(-L)
MD290T280G(-L) 3 882 47713 76341
MD290T355P(-L)
MD290T315G(-L) 3 644 47713 76341
MD290T400P(-L)
MD290T355G(-L) 3 796 47713 76341
MD290T450P(-L)
MD290T400G(-L) 3 796 47713 76341
MD290T500P(-L)
MD290T450G(-L) 3 796 47713 76341
Note:
1. CFM = 0.0283 m
3
/min
2. Effective area means through-hole area.
7KHVSHFL¿FDWLRQLVRQO\DSSOLFDEOHWRVLQJOHXQLWLQVWDOODWLRQLQFDELQHW)RUPXOWLGULYHLQVWDOODWLRQLQFDELQHW
contact Inovance for technical support.
