7
4.3 Cubic Foot Compact Refrigerator
www.insigniaproducts.com
• Locate the refrigerator away from direct sunlight and sources of heat
(stove, heater, radiator, and so on). Direct sunlight may affect the
acrylic coating and heat sources may increase electrical consumption.
Ambient temperature below 50°F (10°C) or above 85°F (29.4°C) will
hinder the performance of this refrigerator. This refrigerator is not
designed for use in a garage or any other outside installation.
• Avoid locating the refrigerator in moist areas.
Leveling your refrigerator
• It is very important for the refrigerator to be level in order to function
properly. If the refrigerator is not leveled during installation, the doors
may not close or seal properly, causing cooling, frost, or moisture
problems.
• To level your refrigerator, you may either turn the leveling foot
clockwise to raise that side to the refrigerator or turn it
counter-clockwise to lower that side.
Providing proper ventilation
Place the refrigerator at lease five inches from the wall to ensure proper
airflow to the compressor. Do not place the refrigerator near any heat
sources, such as a heater or stove, as this may put a strain on the
compressor.
Providing a proper power supply
Check your local power source. This refrigerator requires a 110V-120V,
60Hz power supply.
Use a receptacle that accepts the grounding prong. The power cord is
equipped with a 3-prong (grounding) plug which mates with a standard
3-prong (grounding) wall outlet to minimize the possibility of electric
shock hazard from this refrigerator.
Note
Having someone push against the top of the refrigerator helps to
take some weight off the leveling foot, making it easier to
adjust.
3-prong receptacle
Receptacle box cover
3-prong plug
Grounding lead
Grounding adapter Receptacle box cover
Screw
Receptacle
Using a 3-prong plug and outlet
Using a grounding adapter
NS-CF43SS7_17-0447_MAN_V2_ENG.fm Page 7 Friday, June 2, 2017 11:14 AM
