12
NS-CF43SS7
www.insigniaproducts.com
Reinstalling the doors
1 Reinstall the left leveling foot into the right side and the right leveling
foot into the left side.
2 Install the baffle block on the bottom-right side of the door.
3 Install the bottom hinge on the left bottom of your refrigerator using
the screws you previously removed. Tighten the screws.
4 Align the hole in the bottom right of the refrigerator door with the
bottom hinge pin, then install the door on the hinge pin.
Bottom
hinge
Screws (2)
Leveling feet
Refrigerator door
Baffle block
NS-CF43SS7_17-0447_MAN_V2_ENG.fm Page 12 Friday, June 2, 2017 11:14 AM
