10
NS-CF43SS7
www.insigniaproducts.com
Reversing the door position
Your refrigerator is built with a reversible door. Based on the location
where you plan to use your compact refrigerator, you may find it more
convenient to reverse the position of the door, to have it open from right
to left instead of left to right.
Before you begin
You will need: A 10 mm socket driver and a Phillips screw driver.
• Make sure that your refrigerator is unplugged and empty.
• Have someone available to assist you in the process.
• Keep all of the parts you remove to reuse them later.
• Removing the door requires that the refrigerator be tilted backwards. Rest
the refrigerator on something solid, such as a chair, just below the top
panel.
• Do not lay the refrigerator completely flat so that you do not damage the
coolant system.
Removing the door
1 Remove the two decorative plugs from the top of the refrigerator, then
remove the four screws (two on the top and two on the back) holding
the top onto the refrigerator body.
2 Remove the top of the refrigerator.
3 Remove the two screws holding the top hinge to your refrigerator,
then remove the hinge and the freezer door.
Caution
To avoid injury to yourself or your property, we recommend that
someone assist you during the door reversal process.
Screws (2)
Decorative plugs (2)
Screws (2)
Screws (2)
Top hinge
Freezer door
Pivot pin
Screw
NS-CF43SS7_17-0447_MAN_V2_ENG.fm Page 10 Friday, June 2, 2017 11:14 AM
