24
• In manual zoom mode,
press the ZOOM/C.Fn
button, then turn the
select dial to change the
flash coverage. If AU is
displayed, the flash
coverage will be set
automatically.
Important:
• If you set the flash coverage manually, make sure that it
covers the lens focal length. Otherwise, the picture will
not have a dark periphery.
• When the (low battery) indicator is displayed, the
zoom focal length is always 24mm.
Using the wide panel to extend the
flash coverage
When your flash is in manual zoom mode, you can use the
built-in wide panel to extend the flash coverage for 14mm,
wide-angle lenses.
1 Pull out the wide panel
and place it over the
flash head. The
catchlight panel comes
out at the same time.
2 Push the catchlight panel back in. The flash coverage is
extended to 14 mm.
Note: When the wide panel is over the flash head, the
ZOOM/C.Fn button does not work.
