Insignia NS-FCBK3 User Manual

8
www.insigniaproducts.com
Assembling your file cabinet
STEP 1: Preparing the cabinet bottom and back brace
You n e ed:
1 Insert four wooden dowels (B) into the edges of the bottom panel (4). Be careful not to insert the dowels into the
KD bolt holes. Tap the dowels to seat them.
2 Attach two locking casters (K) to the front edge of the bottom panel (4) and two non-locking casters (J) to the back
edge of the bottom panel, each with four 3.5 x 12 mm screws (G).
B Wooden dowels
7.8 x 30 mm (7)
Phillips screwdriver
4 Bottom panel
5 Back brace
J Caster back
(non-locking) (2)
K Caster front
(locking) (2)
G 3.5× 12 mm
screw (16)
B
K
4
J
G
