37
4-Burner Electric Range
www.insigniaproducts.com
Specifications
Display flashes Power failure. Reset the clock.
Unable to get the display
to show “SF”
Oven control pads were not
pressed properly.
The BAKE and BROIL pads must
be pressed at the same time and
held for 3 seconds.
Strong odor An odor from the insulation
around the inside of the
oven is normal for the first
few times the oven is used.
This is temporary.
Dimensions (H × W × D) 47 3/4 × 29 7/8 × 29 5/8 in. (121.3 × 75.9 × 75.2 cm)
Weight Gross weight: 176 lbs. (80 kg)
Net weight: 174 lbs. (79 kg)
Power requirements 208 ~ 240VAC, 60Hz, 48 ~ 55A
Cooktop elements Right front: 8 in. (20.32 cm) 2,000W
Left front: 6 in. (15.24 cm) 1,500W
Right rear: 6 in. (15.24 cm) 1,500W
Left rear: 8 in. (20.32 cm) 2,000W
Oven element Broil element: 3,410W
Bottom element: 2,585W
Oven temperatures 170° ~ 550° F (76.6° ~ 287.7° C)
Oven light 40W Incandescent E26
PROBLEM POSSIBLE CAUSES WHAT TO DO
