4-9
Connect the System Components
Product Support: www.instron.com
Figure 4-6. 5960 Controller Connections
Computer Interface
Connection (Ethernet)
Service
Input/Output (optional)
Strain 1
(optional)
Strain 2 (optional)
Load
Sync
(for use with AVE)
Service
Expansion port
(optional)
