4. Appendix
4.1. Optical and acoustic signal outputs
Signal output Reason Note
1 green 1 x
Correct code entry
1 red and 12 x 
Incorrect code entry
After 3 consecutive incorrect code
entries, a blocking time of 12 sec.
occurs. Each subsequent incorrect
entry extends the blocking time by
12 sec. Blocking time cannot be
cancelled!
1 green and 2 x 
Change OK
Code changed or additional
functions switched on/off correctly.
1 red and 12 x 
Change invalid
Code changed or additional
functions switched on/off incorrectly.
Repeat procedure.
1 green flashes every 5
sec.
Time delay is
running
While the time delay is running, the
electronic lock does not react to any
key entry.
15 x  then 1 green
Release is running
(time delay expired)
For release times, see
Opening with time delay.
1 red flashes every 5 sec.
Blocking time is
running.
Blocking time cannot be cancelled!
1 green and 2 x 
Blocking time
expired.
Electronic lock can now be opened
with the correct code.
1 alternately flashes red
and green, 10 x and
10 x 
Battery warning
ALKALINE type batteries (not
rechargeable) should be changed
soon.
Codes are preserved when
batteries are changed. Enter code
2x after battery change.
1 green and 1 x  , then
1 red and 1 x 
Keypad has been
manipulated or
changed.
In order to open the electronic lock,
the code has to be entered again.
4.2. Notes
