Names and functions of parts
9
It
De
Remote control
Í button: Press this button to turn the unit on or put it
in standby mode.
Input Selector buttons: Use these buttons to select
the source to playback.
Skip (:/9) buttons (*)
Search (6/5) buttons (*)
Repeat button: Turns repeat play on and off and
selects the mode. (*)
Speaker A/B button: Select the terminals to output
audio from between SPEAKERS A/B.
Direction ( / / / )/Enter buttons: Select items
with the direction buttons and press the Enter button to
confirm.
Setup button: Used to display the setup menu.
CH (i/j) buttons: Select registered stations.
Number buttons
Display button: Change the information shown.
Dimmer button: Use this button to switch the display’s
brightness between normal, moderately dark and dark.
Remote Mode Main button: Switches the remote
control to the mode for operating this unit.
Remote Mode Zone2 button: For use when the unit
is connected with a pre-main amplifier, a power
amplifier or a subwoofer with built-in amplifier in a
separate room and sound is played there.
Pause (;) button (*)
Playback (1) button (*)
Stop (∫) button (*)
Random button: Plays tracks in the folder or playlist
(DLNA) randomly. (*)
Menu button: Press this button to display the menu.
Return button: Returns the display to the previous
state during setting or operation.
Volume 3/4 buttons
Audio button: Use this button to adjust sound quality,
etc.
Muting button: Temporarily mutes audio.
CLR button: Use this button to clear the characters
that you have input.
Sleep button: Press this button to set the sleep timer.
*
Operate with USB storage device play or the home network
feature (DLNA, Home Media).
*
If you do not use the remote control for a long time, remove the
batteries to prevent leakage. Note that keeping consumed
batteries inside may cause corrosion resulting in damage of the
remote control.
Remote control sensor
5 m (Approx.
16 ft.) or less
Batteries
(AAA/R03)
