Integra DTR-4.5 User Manual

11
Front & Rear Panels —Continued
J
OPTICAL DIGITAL (26, 27, 29, 31, 32, 33)
The optical digital audio inputs can be used to con-
nect CD and DVD players, and other components
with an optical digital audio output.
The optical output can be used to connect a CD
recorder or other digital recorder with an optical
digital input.
K
COAXIAL DIGITAL (26, 27, 29, 31, 32, 33)
The coaxial digital audio inputs can be used to con-
nect CD and DVD players, and other components
with a coaxial digital audio output.
L
ZONE 2 SPEAKERS (63)
These terminal posts are for connecting speakers in
Zone 2.
M
FRONT, CENTER, & SURROUND SPEAKERS
(22)
These terminal posts are for connecting your front,
center, and surround speakers.
N
AC OUTLETS (35)
These switched AC outlets can be used to supply
power to other AV components. The type of outlet
depends on the country in which you purchased
your AV receiver. Some models have a single outlet.
O
CD IN (32)
This analog audio input is for connecting a CD
player’s analog audio output.
P
TAPE IN/OUT (32)
This analog audio input and output are for connect-
ing a recorder with an analog audio input and output
(cassette, Mini Disc, etc).
Q
VIDEO 3 IN (26, 30)
Here you can connect a video source (VCR, set-top
box, etc). Input jacks include S-Video, composite
video, and analog audio.
R
VIDEO 2 IN/OUT (28, 30)
Here you can connect a VCR. Input and output
jacks include S-Video, composite video, and analog
audio.
S
VIDEO 1 IN/OUT (28, 30)
Here you can connect a VCR. Input and output
jacks include S-Video, composite video, and analog
audio.
T
DVD IN (27, 28)
Here you can connect a DVD player. Input jacks
include S-Video, composite video, and analog
audio. You can connect a DVD player’s 2-channel
analog audio output or 5.1-channel analog audio
output.
U
ZONE 2 OUT (63)
This analog audio output can be connected to a line
input on an integrated amplifier in Zone 2.
These jacks can can be configured as either line outs
or pre outs on the onscreen setup menus.
V
REMOTE CONTROL (34)
This (Remote Interactive) jack can be con-
nected to an jack on another Integra AV compo-
nent. The AV receiver’s remote controller can then
be used to control that component. To use , you
must make an analog audio connection (RCA)
between the AV receiver and the other AV compo-
nent, even if they are connected digitally.
W
PRE OUT (34)
The SUBWOOFER jack is for connecting a pow-
ered subwoofer.
X
AC INLET (35)
The supplied power cord should be connected here.
DTR-4.5En.book Page 11 Tuesday, August 10, 2004 9:39 AM
