DTR-4.6
PRINTED CIRCUIT BOARD-PARTS LIS
NOTE: THE COMPONENTS IDENTIFIED BY MARK !
ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART NUMBER SPECIFIED.
CAUTION: Replacement for transistor of mark *, if necessary
must be made from the same beta group (hFE) as
the original type.
VIDEO CIRCUIT PC BOARD (NAVD-8657-1F)
CIRCUIT NO. PART NAME DESCRIPTION PART NO. REMARKS
Q2001,Q2002,Q2003 IC NJM2595M 22241946R2
Q2004 IC LC74763-9836 22241779
Q2101 IC ADV7183B 22242202R3
IC(REGULATOR) TA48033AF(TE16L、NQ) or 22278033DR2T or
IC(REGULATOR) BA33BC0FP 22278033DR2RH
IC(REGULATOR) TA48018AF(TE16L、NQ) or 22278018DR2T or
IC(REGULATOR) BA18BC0FP 22278018DR2RH
Q2104 IC ADV7172 22242155R3
Q2106,Q2107 IC LA7106MFP 22241465R2
Q2111 IC NJU7313AM 22242211R2
TR KTC3875-GR or 2216175R2 or
TR 2SC2712-GR 2213145R2
Q2006,Q2007,Q2012 TR RN1443 or 2215510R2 or
Q2013,Q2017,Q2018 TR KRC286S 2217250R2
TR KTA1504-GR or 2216185R2 or
TR 2SA1162-GR 2214375R2
TR KRA102S or 2216220R2 or
TR RN2402 or 2214530R2 or
TR UNR2111 2217110R2
Q2020,Q2023,Q2024 TR RN1443 or 2215510R2 or
Q2025 TR KRC286S 2217250R2
Q2051,Q2052,Q2053 TR KRC101S or 2216330R2 or
Q2054,Q2105 TR RN1401 2214460R2
Q2108,Q2109 TR 2SK3019 2216520R2
D2001,D2002 C-DIODE KDS4148U or 223283R2 or
D2003,D2201 C-DIODE 1SS352 or 223234R2 or
D2202 C-DIODE 1SS355 or 223269R2 or
C-DIODE MA2J111 223279R2
X2001 CRYSTAL HC-49/U0314.318M 3010363
X2101 CRYSTAL FCX-03-28.6363MHz 3010408R2
L2001 CHOKE COIL NCH-1572 231292J056R2
L2002,L2007 CHOKE COIL NCH-1471 or 231237K022R2 or
L2101,L2104,L2105 CHOKE COIL NCH-1587-022K 233533K022R2
Q2102
Q2103
Q2005,Q2201,Q2202
Q2008,Q2009,Q2022
Q2010
