EXPLODED VIEW-PARTS LIST
NOTE: THE COMPONENTS IDENTIFIED BY MARK !
ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART NUMBER SPECIFIED.
CAUTION: Replacement for transistor of mark *, if necessary
must be made from the same beta group (h
FE) as
the original type.
REF.NO. PART NO. DESCRIPTION
A001 27111427A Front bracket
A002 28325756 Knob, standby
A003 801618 3TTB+8B(CU)SR,Screw
A005 27268164 Guide, volume
A008 28133418 Back plate
A009 28192078 Clear plate
A010 27215377 Decorative frame
A011 28198905 Facet
A012 28141650 Cushion
A015 27141787 Retainer HP
A019 28135278 Badge
A020 28141562 t5*30*5,Cushion
A037 838430088GR 3TTB+8B(3BC),Screw
A040 28326231 Knob, volume
A044 28141637 Cushion
A050 27100468A Chassis
A051 27130991A Bracket FR
A052 27190470 KGLS-18S,Holder
A053 27190524 KGLS-14RT,Holder
A054 27190991 Holder
