DTR-4.6
PRINTED CIRCUIT BOARD VIEW 2 Amplifier section
NAPS-8679,
Power
transformer
PC board
U061
U064
NAAF-8682,
Surround back
amplifier PC
board
U062
NAETC-8680,
Thermal detector
PC board
U06
NAAF-8678, Power amplifier PC board
A
1
2
3
4
5
BCD
