PRINTED CIRCUIT BOARD VIEW
POWER AMPLIFIER
SECTION
NAPS-8679,
Power transformer
terminal PC board
DTR-4.6
A
1
2
3
4
5
BCDEFGH
U061
U064
NAAF-8682,
Surround back
amplifier PC board
U062
NAETC-8680,
Thermal detector
PC board
U06
NAAF-8678,Power amplifier PC board
