41
Specifications
AMPLIFIER SECTION
VIDEO SECTION
TUNER SECTION
FM
AM
GENERAL
REMOTE CONTROL
Specifications and features are subject to change without
notice.
Continuous Average
Power output (FTC)
All channels: 70 watts per channel min. RMS at
8 ohms, 2 channels driven from
20 Hz to 20 kHz with no more than
0.08% total harmonic distortion.
90 watts min. RMS at 6 ohms, 2
channels driven from 1 kHz with no
more than 0.1% total harmonic dis-
tortion.
Maximum Power output
(EIAJ)
130 watts at 6 ohms
Total Harmonic Distortion: 0.08% at rated power (Front)
IM Distortion: 0.08% at rated power (Front)
Damping Factor: 60 at 8 ohms (Front)
Input Sensitivity and
Impedance
PHONO: 2.5 mV, 50 kohms
LINE (CD, TAPE, DVD,
VIDEO 1, 2, 3): 300 mV, 50 kohms
MULTICHANNEL INPUT
FRONT L/R, SUR-
ROUND L/R, CENTER: 300 mV, 50 kohms
SUBWOOFER: 53 mV, 50 kohms
COAXIAL 1, 2 (DIGITAL): 0.5 Vp-p, 75 ohms
Output Level and Imped-
ance
Rec out (TAPE, VIDEO 1): 300 mV, 2.2 kohms
Pre out (SUBWOOFER): 1 V, 2.2 kohms
Phono Overload: 70 mV RMS at 1 kHz, 0.5% T.H.D.
Frequency Response: 5 Hz to 100 kHz, +1/–3 dB
RIAA Deviation: 20 Hz to 20 kHz, ±0.8 dB
Tone Control
Bass: ±10 dB at 100 Hz
Treble: ±10 dB at 10 kHz
Signal-to-Noise Ratio
Phono: 80 dB (IHF A, 5 mV input)
CD/Tape: 100 dB (IHF A)
Input sensitivity/Imped-
ance
(DVD, VIDEO 1, 2, 3)
VIDEO (Composite):
S-VIDEO (Y signal):
1 Vp-p, 75 ohms
1 Vp-p/75 ohms
Output Level/Imped-
ance
(VIDEO 1, MONITOR)
VIDEO (Composite):
S-VIDEO (Y signal):
1 Vp-p, 75 ohms
0.28 Vp-p/75 ohms
Tuning Range: 87.5 — 108.0 MHz
Usable Sensitivity
Mono: 11.2 dBf, 1.0 µV (75 ohms)
Stereo: 17.2 dBf, 2.0 µV (75 ohms)
50 dB Quieting Sensitivity
Mono: 17.2 dBf, 2.0 µV (75 ohms)
Stereo: 37.2 dBf, 20 µV (75 ohms)
Capture Ratio: 2.0 dB
Image Rejection Ratio: 40 dB
IF Rejection Ratio: 90 dB
Signal-to-Noise Ratio
Mono: 76 dB
Stereo: 70 dB
Alternate Channel Atten-
uation:
55 dB
Selectivity: 50 dB (DIN)
AM Suppression Ratio: 50 dB
Total Harmonic Distortion
Mono: 0.2%
Stereo: 0.3%
Frequency Response: 30 Hz — 15 kHz, ±1.0 dB
Stereo Separation: 45 dB at 1 kHz
30 dB at 100 Hz — 10 kHz
Tuning Range: 530—1,710 kHz (10 kHz steps)
Usable Sensitivity: 30 µV
Image Rejection Ratio: 40 dB
IF Rejection Ratio: 40 dB
Signal-to-Noise Ratio: 40 dB
Total Harmonic Distortion: 0.7%
Power Supply: AC 120 V, 60 Hz
Power Consumption: 3.9 A
Dimensions (W
× H × D): 17-1/8" × 6-7/8" × 15-5/8"
Weight: 27.3 lbs.
Transmitter: Infrared
Signal range: Approx. 5 meters, 16 ft.
Power supply: Two “AA” batteries (1.5 V × 2)
