Advanced Operations
En-60
■ Left, Front Wide Left, Front High Left, Center,
Front High Right, Front Wide Right, Right,
Surround Right, Surround Back Right, Surround
Back Left, Surround Left, Subwoofer
` Specify the distance from each speaker to your
listening position.
Note
• Speakers that you set to “No” or “None” in “Speaker
Configuration” cannot be selected (➔ page 58).
•When the “Powered Zone 2” setting is set to “Yes” and Zone 2
is turned on, the surround back and front high speakers cannot be
used.
•When the “Powered Zone 3” setting is set to “Yes” and Zone 3
is turned on, the surround and surround back speakers cannot be
used.
Level Calibration
Here you can adjust the level of each speaker with the
built-in test tone so that the volume of each speaker is the
same at the listening position.
■ Left, Front Wide Left, Front High Left, Center
*1
,
Front High Right, Front Wide Right, Right,
Surround Right, Surround Back Right, Surround
Back Left, Surround Left
` –12.0dB to 0.0dB to +12.0dB in 0.5 dB steps.
■ Subwoofer
*1
` –15.0dB to 0.0dB to +12.0dB in 0.5 dB steps.
Note
• These settings cannot be calibrated when the AV receiver is
muted.
• Speakers that you set to “No” or “None” in “Speaker
Configuration” cannot be selected (➔ page 58).
• When the “Powered Zone 2” setting is set to “Yes” and Zone 2
is turned on, the surround back and front high speakers cannot be
used.
• When the “Powered Zone 3” setting is set to “Yes” and Zone 3
is turned on, the surround and surround back speakers cannot be
used.
• The test tone is output at the standard level for THX, which is
0 dB (absolute volume setting 82). If you normally listen at
volume settings below this, be careful because the test tone will
be much louder.
*1
For the center speaker and subwoofer, the level settings made
by using the Quick Setup are saved in this menu (➔ page 50).
Tip
• If you’re using a handheld sound level meter, adjust the level of
each speaker so that it reads 75 dB SPL at the listening position,
measured with C-weighting and slow reading.
Equalizer Settings
With the Equalizer settings, you can adjust the tone of
speakers individually with a 15-band equalizer. The
volume of each speaker can be set (➔ page 60).
■ Manual Equalizer
` On:
You can adjust the equalizer for each speaker
manually. Continue with the following procedure:
` Off
:
Tone off, response flat.
Note
• When the Direct listening mode is selected, the equalizer settings
have no effect.
• If “Audyssey” is enabled, it prevails over this setting
(➔ page 66).
This setting is set automatically by
Audyssey MultEQ
®
XT32 Room Correction and
Speaker Setup (➔ page 35).
1
Press w to select “Channel”, and then use e/r to
select a speaker.
2
Use q/w to select a frequency, and then use the e/r
to adjust the level at that frequency.
The volume at each frequency can be adjusted from
–6dB to 0dB to +6dB in 1 dB steps.
Tip
• You can select: “25Hz”, “40Hz”, “63Hz”, “100Hz”,
“160Hz”, “250Hz”, “400Hz”, “630Hz”, “1000Hz”,
“1600Hz”, “2500Hz”, “4000Hz”, “6300Hz”, “10000Hz”
or “16000Hz”. And for the subwoofer, “25Hz”, “40Hz”,
“63Hz”, “100Hz”, or “160Hz”.
• Low frequencies (e.g., 25Hz) affect bass sounds; high
frequencies (e.g., 16000Hz) affect treble sounds.
3
Use q to select “Channel”, and then use e/r to
select another speaker.
Repeat steps 1 and 2 for each speaker.
You cannot select speakers that you set to “No” or
“None” in the “Speaker Configuration”
(➔ page 58).
To Next Page
