Integra DTR-6.5 - Page 107

DTR-6.5
P6804A 25055701 NPLG-5P657
P6953A 25055806 NPLG-17P762
P931A 25055701 NPLG-5P657
Retainer
P6011A 27141860 (BUS-D)
Heat sink
D6904A 27160499 RAD-164
Screws
D6904B,D6905B 82143010 3P+10FN(BC)
Secondary circuit PC board (NAETC-8398-1D/1E)
CIRCUIT NO. PART NO. DESCRIPTION
JL6952B 25051109 NSCT-5P896,Socket
Speaker terminal PC board (NAETC-8399-1D/1E)
CIRCUIT NO. PART NO. DESCRIPTION
Diodes
D6803,D6805 223163 or 1SS133 or
D6807 223205 or 1SS270A or
223222 WG713A
Coils
L6803,L6804 231176S S-1.3C <A>
L6805,L6806 231176S S-1.3C <A>
Capacitors
C6803,C6805 374721034 ECQ-B50V-103J,Plastic film
C6807 374721034 ECQ-B50V-103J,Plastic film
C6843,C6844 374721034 ECQ-B50V-103J,Plastic film <A>
C6845,C6846 374721034 ECQ-B50V-103J,Plastic film <A>
C6847,C6848 374721034 ECQ-B50V-103J,Plastic film <A>
C6853,C6854 374721024 ECQ-B50V-102J,Plastic film <A>
C6855,C6856 374721024 ECQ-B50V-102J,Plastic film <A>
C6857,C6858 374721024 ECQ-B50V-102J,Plastic film <A>
Resistors
R6803,R6804 417342204 R16J-22,Carbon <A>
R6805,R6806 417342204 R16J-22,Carbon <A>
R6813,R6814 417342204 R16J-22,Carbon <A>
R6815,R6816 417342204 R16J-22,Carbon <A>
Relays
RL6803,RL6805 25065618 NRL-2P5A-DC24-158
RL6807 25065618 NRL-2P5A-DC24-158
CIRCUIT NO. PART NO. DESCRIPTION
