Integra DTR-6.5 - Page 108

DTR-6.5
P6802 25060391 NTM-8PDMN322 <D>
25060392 NTM-8PDMN323 <A>
P6803 25060389 NTM-4PDMN320 <D>
25060385 NTM-4PDMN316 <A>
Sockets
JL6802B,JL6805B 25050281 NSCT-4P109
JL6803B 25050282 NSCT-5P110
Holders
P6850,P6851 27190926 KGPS-18RF
Speaker terminal F/C PC board (NAETC-8400-1D/1E)
CIRCUIT NO. PART NO. DESCRIPTION
Diodes
D6600,D6602 223163 or 1SS133 or
223205 or 1SS270A or
223222 WG713A
Coils
L6600,L6601 231176S S-1.3C <A>
L6602 231176S S-1.3C <A>
Capacitors
C6600,C6602 374721034 ECQ-B50V-103J,Plastic film
C6640,C6641 374721034 ECQ-B50V-103J,Plastic film <A>
C6642 374721034 ECQ-B50V-103J,Plastic film <A>
C6650,C6651 374721024 ECQ-B50V-102J,Plastic film <A>
C6652 374721024 ECQ-B50V-102J,Plastic film <A>
Resistors
R6600,R6601 417342204 R16J-22,Carbon <A>
R6602,R6610 417342204 R16J-22,Carbon <A>
R6611,R6612 417342204 R16J-22,Carbon <A>
Relays
RL6600,RL6602 25065618 NRL-2P5A-DC24-158
Terminals
P6600 25060389 NTM-4PDMN320 <D>
25060385 NTM-4PDMN316 <A>
P6602 25060387 NTM-2PDMN318 <D>
25060388 NTM-2PDMN319 <A>
Sockets
P6804B 25051230 NSCT-5P1020
JL6805A 25051108 NSCT-4P895
Plugs
P6800B,P6801B 25055722 NPLG-3P678
