DTR-6.5
Thermal detector PC board (NAETC-8402-1D/1E)
CIRCUIT NO. PART NO. DESCRIPTION
Resistors
R6380 4000217 PTFL04BF471Q2N34B0 (80）,Thermistor
R6381 4000220 PTFL04BC471Q2N34B0 (110）,Thermistor
Socket
JL6402C 25051088 NSCT-4P875
Video terminal PC board ass'y (NAVD-8464-1D/1E)
CIRCUIT NO. PART NO. DESCRIPTION
ICs
Q2001,Q2002,Q2003 22241946R2 NJM2595M
Q2004 22241779 LC74763-9836
Q2011 22241221R2 TC9164AF
Q2101 22242154R3 ADV7183A
Q2102 22278033DR2NE or MPC2933T or
22278033DR2JR NJM2391DL1-33
Q2103 22278018ER2NE MPC2918T
Q2104 22242155R3 ADV7172
Q2106,Q2107 22241465R2 LA7106MFP
CIRCUIT NO. PART NO. DESCRIPTION
Transistors
Q2005,Q2201,Q2202 2216175R2 or KTC3875-GR or
2213145R2 2SC2712-GR
Q2006,Q2007 2215510R2 RN1443
Q2008,Q2009,Q2022 2216185R2 or KTA1504-GR or
2214375R2 2SA1162-GR
Q2010 2214530R2 or RN2402 or
2216220R2 KRA102S
Q2012,Q2013,Q2017 2215510R2 RN1443
Q2018,Q2020 2215510R2 RN1443
Q2023,Q2024,Q2025 2215510R2 RN1443
Q2105,Q6801,Q6802 2216330R2 or KRC101S or
2214460R2 RN1401
Q2108,Q2109 2216520R2 2SK3019
Diodes
D2001,D2002,D2003 223234R2 or 1SS352 or
D2201,D2202 223269R2 1SS355
D6801,D6802 223234R2 or 1SS352 or
223269R2 1SS355
Coils
L2001 231292J056R2 NCH-1572
