Integra DTR-7.3 Service Manual

REF. NO. PART NO. DESCRIPTION
1 27111304 Front bracket
2 27141787 Retainer HP
3 838430088 3TTB+8B(BC), Self-tapping screw
4 838130088 3TTB+8B, Self-tapping screw
5 28325964A Knob CL
7 28191948 Clear plate
8 28133387 Back plate
9 28198905 Facet
10 82143010 3P+10FN(BC), Pan head screw
12 28198933 Facet 5
13 28198936 Facet 6
14 28325965 Knob, tuning
15 27215363 Decorative frame
16 28135278 Badge
28 28325913 Knob, volume
30 880016 P3035B, Plastic rivet
31 27255004 CS-1U, Clip
32 28325756 Knob, standby
33 27100408-1A Chassis
34 27130870A Bracket, power transformer
35 27190965 Holder
36 27190693A KGLS-6RF, Holder
37 27190266 KGLS-12RF, Holder
38 27190164 KGLS-14S, Holder
39 830440089 4TTC+8C(BC), Self-tapping screw
41 28141484 Cushion
42 27191112 KGPS-6RF, Holder
43 27141797 Retainer, fan
44 27150470 Shield plate, fan
45 838450108 5TTB+10B(BC), Self-tapping screw
47 27150471 Shield plate
49 27150474 Shield plate, wire
52 27160489A Heat sink
53 801606 3SMH10W.SW+15B(CU), Special screw
54 27141681 Retainer, PC board
55 27141798 Retainer R, heat sink
56 27141799 Retainer L, heat sink
57 27130869 Bracket, heat sink
58 27130745 Bracket
61 838430107 3TTB+10S(BC), Self-tapping screw
62 28184817-1 Top cover
63 29362772 Label, cover
64 838440089 4TTB+8C(BC), Self-tapping screw
65 29363226 Label, display
66 838430088 3TTB+8B(BC), Self-tapping screw
67 27175319B Leg
68 28141494 Cushion
69 831430088 3TTW+8B(BC), Self-tapping screw
70 27123041-1 Rear panel <D>
27123043-1 Rear panel <A>
71 838430088 3TTB+8B(BC), Self-tapping screw
72 87643010 W3*10F(BC), Flat washer
73 838930088 3TTB+8B(UN), Self-tapping screw
74 838430068 3TTB+6B(BC), Self-tapping screw
75 838440089 4TTB+8C(BC), Self-tapping screw
78 28141467 Cushion
81 27212448 Front panel
83 27190470 KGLS-18S, Holder
86 260208 Binder
87 260258 Binder
91 27225149 Shield case
CAUTION: Replacement for transistor of mark *, if necessary
must be made from the same beta group (h
FE) as
the original type.
NOTE: THE COMPONENTS IDENTIFIED BY MARK !
ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART NUMBER SPECIFIED.
Note:
<D>: 120V model only
<A>: Australian model only
REF. NO. PART NO. DESCRIPTION
92 27150485 Shield plate
93 29362609 Label, power transformer
97 223025 AC262, Isolated sheet
98 29363264 Label MAC
E821 24502310 D09T-24PG10(EX), Fan
F6901,F6902 252100 ! 10A-EAK, Fuse <A>
252199 ! 10A-UL, Fuse <D>
F901 252199 ! 10A-UL, Fuse <D>
F902 252077, ! 4A-SE-EAK,
252243 or ! 4A-SE-TL250V or
252277 ! 4A-SE-TL250V, Fuse <A>
F903 252075, ! 2.5A-SE-EAK,
252241 or ! 2.5A-SE-TL250V or
252275 ! 2.5A-SE-TL250V, Fuse <A>
F9501,F9502 252160 or ! 2.5A-UL/T-237 or
252254 ! 2.5A-T/UL-ST2, Fuse <D>
252075, ! 2.5A-SE-EAK,
252241 or ! 2.5A-SE-TL250V or
252275 ! 2.5A-SE-TL250V, Fuse <A>
F9501A 29363313 T2.5AL1.6AL250V, Label, fuse <A>
F9503,F9504 252158 or ! 1.6A-UL/T-237 or
252252 ! 1.6A-T/UL-ST2, Fuse <D>
252073, ! 1.6A-SE-EAK,
252239 or ! 1.6A-SE-TL250V or
252273 ! 1.6A-SE-TL250V, Fuse <A>
P1010 2047151012 NCFC7-151012, Flexible cable
P2901 2047191012 NCFC7-191012, Flexible cable
P6009 27141825 Retainer, bus
P602 2009990753UL NSAS-8P1059, Socket
P603 204406027 NCFC4-062512, Flexible cable
P603C 79012 Tube FFC
P6205 27141826 Retainer, bus
P7201 2047312512 NCFC7-312512, Flexible cable
P7701 2047051012 NCFC7-051012,Flexible cable
Q6050~Q6056 2202822 * 2SC5200-R, Transistor
2202823 or * 2SC5200-O or
Q6060~Q6066 2202812 * 2SA1943-R, Transistor
2202813 or * 2SA1943-O or
Q9422A 223026 Isolated sheet
Q9422B 223032 TO-66(1), Isolated washer
T901 2301653 ! NPT-1454D, Power transformer <D>
2301654 ! NPT-1454P, Power transformer <A>
U1 1A956587-1N NADG-7687-1N, DSP circuit PC board ass'y
U2 1A956562-2 NADG-7662-2,Net-tune circuit PC board ass'y
U6 1A956590-1R NAAF-7690-1R, F/C ch. driver circuit PC
board ass'y <D>
1A956590-1T NAAF-7690-1T, F/C ch. driver circuit PC
board ass'y <A>
U7 1A956591-1R NAPS-7691-1R, Primary circuit PC board
ass'y <D>
1A956591-1T NAPS-7691-1T, Primary circuit PC board
ass'y <A>
U8 1A956592-1R NAPS-7692-1R, Bias selector relay PC board
ass'y <D>
1A956592-1T NAPS-7692-1T, Bias selector relay PC board
ass'y <A>
U10 1A956594-1R NAETC-7694-1R, F/C ch. Speaker terminal
PC board ass'y <D>
1A956594-1T NAETC-7694-1T, F/C ch. Speaker terminal
PC board ass'y <A>
DTR-7.3
EXPLODED VIEW-PARTS LIST
