NOTE: THE COMPONENTS IDENTIFIED BY MARK !
ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART NUMBER SPECIFIED.
Note:
<D>: 120V model only
<A>: Australian model only
CAUTION: Replacement for transistor of mark *, if necessary
must be made from the same beta group (H
FE) as
the original type.
CIRCUIT NO. PART NO. DESCRIPTION
Capacitors
C3862,C3863 374721224 1200pF+/-5%,50V,Plastic
C3864,C3865 374722724 2700pF+/-5%,50V,Plastic
C4010,C4011 393381007 10uF,50V, Elect.
C4120,C4121 354742219 or 220uF,16V, Elect.or
C4320~C4325 394642217 220uF,16V, Elect.
C4200~C4207 393381007 10uF,50V, Elect.
C4217 374721024 1000pF+/-5%,50V,Plastic
C4220~C4227 393380107 1uF,50V, Elect.
C4230~C4237 393384707 47uF,50V, Elect.
C4410~C4412 374721015 100pF+/-10%,50V,Plastic
C4417 374721024 1000pF+/-5%,50V,Plastic
C4420~C4422 393384707 47uF,50V, Elect.
C4430~C4432 374721044 0.1uF+/-5%,50V,Plastic
C4440~C4442 374721534 0.015uF+/-5%,50V,Plastic
C4540 354721019 or 100uF,6.3V, Elect.or
394621017 100uF,6.3V, Elect.
C4600~C4602 393384707 47uF,50V, Elect.
C4607 393384707 47uF,50V, Elect.
C4610~C4617 374721024 1000pF+/-5%,50V,Plastic
C4800,C4801 354741009 10uF,16V, Elect.
C4802,C4803 354780229 2.2uF,50V, Elect.
C4806,C4807 354721019 100uF,6.3V, Elect.
C4808,C4809 374722224 2200pF+/-5%,50V,Plastic
C4920,C4921 354742219 or 220uF,16V, Elect.or
394642217 220uF,16V, Elect.
Resistors
R4120,R4121 443522204 22ohm+/-5%, 1/2W, Metal oxide
R4320~R4325 443522204 22ohm+/-5%, 1/2W, Metal oxide
R4920,R4921 443522204 22ohm+/-5%, 1/2W, Metal oxide
Terminals
P3600,P4600 25045708 NPJ-4PDGPRW503
P3601,P4601 25045710 NPJ-4PDELNT505
Sockets
P4010B 25051235 NSCT-10P1025
P4011B,P4020B 25051240 NSCT-15P1030
Plugs
P4012A 25055734 NPLG-3P690
P5003E 25055152 NPLG-8P136
P5004E 25055153 NPLG-9P137
Bars
J4220~J4223 27141851 BBL60
Holders
P4610C~P4610
27190540-1 Clamp
P5004G 27190608-1 Clamp
Audio terminal PC board (NAAF-7719-1P)
CIRCUIT NO. PART NO. DESCRIPTION
ICs
Q1001 222780125 78M12HF
Q3000,Q3020 22241383R2 or NJM4565M-D or
Q3021 22240489R1NE MPC4570G2-T1(MST)
Q3100 22241639R2 TC9273F-017
Capacitors
C1002,C1007 354741009 or 10uF,16V, Elect.or
394641007 10uF,16V, Elect.
C1003,C1006 354780339 or 3.3uF,50V, Elect.or
394680337 3.3uF,50V, Elect.
C3000,C3001 374722215 220pF+/-10%,50V,Plastic
C3002,C3003 393384707 47uF,50V, Elect.
C3004,C3005 374721524 1500pF+/-5%,50V,Plastic
C3006,C3007 354722219 220uF,6.3V, Elect.
C3008,C3009 374721234 0.012uF+/-5%,50V,Plastic
C3010,C3011 374723924 3900pF+/-5%,50V,Plastic
C3020~C3023 374723315 330pF+/-10%,50V,Plastic
C3026~C3029 393384707 47uF,50V, Elect.
CIRCUIT NO. PART NO. DESCRIPTION
Capacitors
C3120,C3121 354742219 or 220uF,16V, Elect.or
394642217 220uF,16V, Elect.
C3122,C3123 354744709 or 47uF,16V, Elect.or
394644707 47uF,16V, Elect.
Resistors
R3120,R3121 443522204 22ohm+/-5%, 1/2W, Metal oxide
Terminals
P3000,P3001 25045582 or NPJ-4PDRW393 or
25045491 NPJ-4PDBL308
Sockets
P1010A 25052248, NSCT-15P2145,
25051859 or NSCT-15P1646 or
25052061 NSCT-15P1848
P3010B 25051232 NSCT-7P1022
P3011B 25051240 NSCT-15P1030
Vidoe terminal PC board (NAAF-7720-1P)
CIRCUIT NO. PART NO. DESCRIPTION
ICs
Q3200~Q3205 22241383R2 or NJM4565M-D or
Q3200~Q3205 22240489R1NE MPC4570G2-T1(MST)
Q3300 22240829 TC9274N-008
Q3400 22241383R2 or NJM4565M-D or
22240489R1NE MPC4570G2-T1(MST)
Transistors
Q3410~Q3413 2215410R2 RN1441
Capacitors
C3200~C3203 374723315 330pF+/-10%,50V,Plastic
C3205~C3209 374723315 330pF+/-10%,50V,Plastic
C3212~C3223 393384707 47uF,50V, Elect.
C3250,C3251 393381007 10uF,50V, Elect.
C3252 354741009 or 10uF,16V, Elect.or
394641007 10uF,16V, Elect.
C3320,C3321 354742219 or 220uF,16V, Elect.or
394642217 220uF,16V, Elect.
C3400~C3403 393384707 47uF,50V, Elect.
C3404,C3405 374721024 1000pF+/-5%,50V,Plastic
Resistors
R3320,R3321 443522204 22ohm+/-5%, 1/2W, Metal oxide
Terminals
P3200~P3203 25045582 or NPJ-4PDRW393 or
25045491 NPJ-4PDBL308
Sockets
P3210B,P3211B 25051232 NSCT-7P1022
Plugs
P3220A 25055133 NPLG-3P117
P602A 25055148 NPLG-4P132
Front video PC board (NAETC-7721-1P)
CIRCUIT NO. PART NO. DESCRIPTION
Terminal
P2510 25045675 NPJ-3PDB473
Sockets
P2506B 2009990575UL NSAS-10P0784
P2508 25051569 NSCT-4P1356
P3220B 2009990420 NSAS-6P0564
DTR-7.3
PRINTED CIRCUIT BOARD-PART LIST 6
