56
En
Level Calibration
Here you can adjust the level of each speaker with the
built-in test tone so that the volume of each speaker is the
same at the listening position.
Left, Front Wide Left, Front High Left, Center
*1
,
Front High Right, Front Wide Right, Right,
Surround Right, Surround Back Right,
Surround Back Left, Surround Left
` –12.0dB to 0.0dB to +12.0dB in 0.5 dB step.
Subwoofer 1
*1
, Subwoofer 2
*1*2
` –15.0dB to 0.0dB to +12.0dB in 0.5 dB step.
Note
Speakers that you set to “No” or “None” in the
Speaker Configuration” cannot be selected ( 54).
The speakers cannot be calibrated while the AV receiver is
muted.
The test tone is output at the standard level for THX, which is
0 dB (absolute volume setting 82). If you normally listen at vol-
ume settings below this, be careful because the test tone will be
much louder.
•TheLevel Calibration” setting cannot be selected if “Audio
TV Out” setting is set to “On”.
*1
For the center speaker and subwoofer, the level settings made
by using the Home menu are saved ( 27).
*2
If the “Subwoofer” setting is set to “1ch”, this setting cannot
be selected ( 54).
Tip
If you’re using a handheld sound level meter, adjust the level of
each speaker so that it reads 75 dB SPL at the listening position,
measured with C-weighting and slow reading.
Equalizer Settings
With the Equalizer settings, you can adjust the tone of
speakers individually with a 15-band equalizer. The vol-
ume of each speaker can be set ( 56).
Equalizer
` Manual:
You can adjust the equalizer for each speaker manu-
ally. If you selected “Manual”, continue with this
procedure.
` Audyssey:
This is selected automatically by
Audyssey MultEQ XT32 Room Correction and
Speaker Setup function. The Audyssey indicator will
light ( 9) and “Dynamic EQ” and
Dynamic Volume” become available ( 60).
When “Audyssey” is selected, “Dolby Volume
becomes “Off” automatically ( 58).
` Off
:
Tone off, response flat.
This setting is set automatically by
Audyssey MultEQ
®
XT32 Room Correction and
Speaker Setup function ( 29).
This setting is set automatically by
Audyssey MultEQ XT32 Room Correction and Speaker
Setup function ( 29).
1
Press w to select “Channel”, and then use
e/r to select a speaker.
2
Use q/w to select a frequency, and then use
the e/r to adjust the level at that frequency.
The volume at each frequency can be adjusted
from –6dB to 0dB
to +6dB in 1 dB steps.
Note
You can select: “25Hz”, “40Hz”, “63Hz”,
100Hz”, “160Hz”,250Hz”, “400Hz”, “630Hz”,
1000Hz”, “1600Hz”, “2500Hz”, “4000Hz”,
6300Hz”, “10000Hz”, or “16000Hz”. And for the
subwoofer, “25Hz”, “40Hz”, “63Hz”, “100Hz”, or
160Hz”.
While the Direct listening mode is selected, the
equalizer settings have no effect.
Tip
Low frequencies (e.g., 63Hz) affect bass sounds;
high frequencies (e.g., 16000Hz) affect treble
sounds.
3
Use q to select “Channel”, and then use e/r
to select another speaker.
Repeat steps 1 and 2 for each speaker.
You cannot select speakers that you set to “No
or “None” in the “Speaker Configuration
( 54).
