30
For SATA device support Legacy OS (Like Dos), Please select [Legacy] for
compatible.
Acoustic Management Configuration
Press [Enter] to go to enable or disable ‘Automatic Acoustic Management’.
ME Configuration
Press [Enter] to go to ME FW Image Re-Flash to enable or disable ME FW Image
Re-Flash function.
USB Configuration
Press [Enter] to make settings for the following sub-items:
Legacy USB Support
The optional settings are: [Enabled]; [Disabled]; [Auto].
[Enabled]: To enable legacy USB support.
[Auto]: To disable legacy support if no USB devices are connected.
[Disabled]: to keep USB devices available only for EFI specification,
EHCI Hand-off
This is workaround for OSes without EHCI hand-off support. The EHCI ownership
change should be claimed by EHCI driver.
The optional settings are: [Disabled]; [Enabled].
USB Mass Storage Driver Support
The optional settings are: [Disabled]; [Enabled].
Port 60/64 Emulation
The optional settings are: [Disabled]; [Enabled].
This should be set as ‘Enabled’ for the complete USB keyboard legacy support for
non-USB aware OSes.
Super I/O Configuration
Press [Enter] to make settings for the following sub-items:
Super IO Configuration
Serial Port 1 Configuration
Press [Enter] to make settings for the following items:
Serial Port
Use this item to enable or disable serial port (COM).
Change Settings
Use this item to select an optimal setting for super IO device.
