RS232 or RS485 Select
The optional settings are: [RS232]; [RS485].
 Serial Port 2 Configuration/Serial Port 3 Configuration / Serial Port 4
Configuration
Press [Enter] to make settings for the following items:
Serial Port
Use this item to enable or disable serial port (COM).
Change Settings
Use this item to select an optimal setting for super IO device.
 Parallel Port Configuration
Press [Enter] to make settings for the following items:
Parallel Port Configuration
Parallel Port
Use this item to enable or disable parallel port (LPT/LPTE).
Change Settings
Use this item to select an optimal setting for super IO device.
Device Mode
Use this item to change the printer port mode.
The optional settings are: [Standard Parallel Port Mode]; [EPP Mode]; [ECP Mode];
[EPP Mode & ECP Mode].
WatchDog Timer
Use this item to enable or disable WatchDog Timer Control. When set as
[Enabled], the following sub-items shall appear:
WatchDog Timer Value
User can set a value in the range of [1] to[ 65535].
WatchDog Timer Unit
The optional settings are: [Min.]; [Sec.].
 H/W Monitor
Press [Enter] to view current CPU health status and make settings for the following
sub-items:
Shutdown Temperature Configuration
Use this item to select system shutdown temperature.
The optional settings are: [Disabled]; [60C/140F]; [65C/149F]; [70C/158F];
