Land Listing and Signal Descriptions

Datasheet 47

D23# F11 Source Synch Input/Output

D24# F12 Source Synch Input/Output

D25# D13 Source Synch Input/Output

D26# E13 Source Synch Input/Output

D27# G13 Source Synch Input/Output

D28# F14 Source Synch Input/Output

D29# G14 Source Synch Input/Output

D30# F15 Source Synch Input/Output

D31# G15 Source Synch Input/Output

D32# G16 Source Synch Input/Output

D33# E15 Source Synch Input/Output

D34# E16 Source Synch Input/Output

D35# G18 Source Synch Input/Output

D36# G17 Source Synch Input/Output

D37# F17 Source Synch Input/Output

D38# F18 Source Synch Input/Output

D39# E18 Source Synch Input/Output

D40# E19 Source Synch Input/Output

D41# F20 Source Synch Input/Output

D42# E21 Source Synch Input/Output

D43# F21 Source Synch Input/Output

D44# G21 Source Synch Input/Output

D45# E22 Source Synch Input/Output

D46# D22 Source Synch Input/Output

D47# G22 Source Synch Input/Output

D48# D20 Source Synch Input/Output

D49# D17 Source Synch Input/Output

D50# A14 Source Synch Input/Output

D51# C15 Source Synch Input/Output

D52# C14 Source Synch Input/Output

D53# B15 Source Synch Input/Output

D54# C18 Source Synch Input/Output

D55# B16 Source Synch Input/Output

D56# A17 Source Synch Input/Output

D57# B18 Source Synch Input/Output

D58# C21 Source Synch Input/Output

D59# B21 Source Synch Input/Output

D60# B19 Source Synch Input/Output

D61# A19 Source Synch Input/Output

D62# A22 Source Synch Input/Output

Table 4-1. Alphabetical Land

Assignments

Land Name

Land

Signal Buffer

Type

Direction

D63# B22 Source Synch Input/Output

DBI0# A8 Source Synch Input/Output

DBI1# G11 Source Synch Input/Output

DBI2# D19 Source Synch Input/Output

DBI3# C20 Source Synch Input/Output

DBR# AC2 Power/Other Output

DBSY# B2 Common Clock Input/Output

DEFER# G7 Common Clock Input

DP0# J16 Common Clock Input/Output

DP1# H15 Common Clock Input/Output

DP2# H16 Common Clock Input/Output

DP3# J17 Common Clock Input/Output

DRDY# C1 Common Clock Input/Output

DSTBN0# C8 Source Synch Input/Output

DSTBN1# G12 Source Synch Input/Output

DSTBN2# G20 Source Synch Input/Output

DSTBN3# A16 Source Synch Input/Output

DSTBP0# B9 Source Synch Input/Output

DSTBP1# E12 Source Synch Input/Output

DSTBP2# G19 Source Synch Input/Output

DSTBP3# C17 Source Synch Input/Output

FC1 G2 Power/Other Input

FC2 R1 Power/Other Input

FC3 J2 Power/Other Input

FC4 T2 Power/Other Input

FC5 F2 Common Clock Input

FC6 H2 Power/Other Input

FC7 G5 Source Synch Output

FC11 AM5 Power/Other Output

FC12 AM7 Power/Other Output

FC16 AN7 Power/Other Output

FERR#/PBE# R3 Asynch GTL+ Output

GTLREF H1 Power/Other Input

GTLREF_SEL H29 Power/Other Output

HIT# D4 Common Clock Input/Output

HITM# E4 Common Clock Input/Output

IERR# AB2 Asynch GTL+ Output

IGNNE# N2 Asynch GTL+ Input

INIT# P3 Asynch GTL+ Input

ITP_CLK0 AK3 TAP Input

Table 4-1. Alphabetical Land

Assignments

Land Name

Land

Signal Buffer

Type

Direction

Questions and Answers:

Need help?

Do you have a question about the Intel 520J - Pentium 4 2.80GHz 800MHz 1MB Socket 775 CPU and is the answer not in the manual?

Intel 520J - Pentium 4 2.80GHz 800MHz 1MB Socket 775 CPU Specifications

General

Clock Speed	2.80 GHz
Front Side Bus Speed	800 MHz
L2 Cache	1 MB
Socket Type	LGA 775
Core	Prescott
Lithography	90 nm
Thermal Design Power (TDP)	84 W
Instruction Set	x86
Virtualization Technology	No
64-bit Support	Yes
Hyper-Threading	Yes
Integrated Graphics	No
Processor Model	Intel Pentium 4 520J
Extensions	SSE2, SSE3
