Land Listing and Signal Descriptions
48 Datasheet
ITP_CLK1 AJ3 TAP Input
LINT0 K1 Asynch GTL+ Input
LINT1 L1 Asynch GTL+ Input
LL_ID0 V2 Power/Other Output
LL_ID1 AA2 Power/Other Output
LOCK# C3 Common Clock Input/Output
MCERR# AB3 Common Clock Input/Output
MSID0 W1 Power/Other Output
MSID1 V1 Power/Other Output
PROCHOT# AL2 Asynch GTL+ Input/Output
PWRGOOD N1 Power/Other Input
REQ0# K4 Source Synch Input/Output
REQ1# J5 Source Synch Input/Output
REQ2# M6 Source Synch Input/Output
REQ3# K6 Source Synch Input/Output
REQ4# J6 Source Synch Input/Output
RESERVED A20
RESERVED AC4
RESERVED AE3
RESERVED AE4
RESERVED AE6
RESERVED AH2
RESERVED C9
RESERVED D1
RESERVED D14
RESERVED D16
RESERVED E23
RESERVED E24
RESERVED E5
RESERVED E6
RESERVED E7
RESERVED F23
RESERVED F29
RESERVED F6
RESERVED G10
RESERVED B13
RESERVED J3
RESERVED N4
RESERVED N5
RESERVED P5
Table 4-1. Alphabetical Land
Assignments
Land Name
Land
#
Signal Buffer
Type
Direction
RESERVED Y3
RESERVED D23
RESERVED AK6
RESERVED G6
RESET# G23 Common Clock Input
RS0# B3 Common Clock Input
RS1# F5 Common Clock Input
RS2# A3 Common Clock Input
RSP# H4 Common Clock Input
SKTOCC# AE8 Power/Other Output
SMI# P2 Asynch GTL+ Input
STPCLK# M3 Asynch GTL+ Input
TCK AE1 TAP Input
TDI AD1 TAP Input
TDO AF1 TAP Output
TESTHI0 F26 Power/Other Input
TESTHI1 W3 Power/Other Input
TESTHI2 F25 Power/Other Input
TESTHI3 G25 Power/Other Input
TESTHI4 G27 Power/Other Input
TESTHI5 G26 Power/Other Input
TESTHI6 G24 Power/Other Input
TESTHI7 F24 Power/Other Input
TESTHI8 G3 Power/Other Input
TESTHI9 G4 Power/Other Input
TESTHI10 H5 Power/Other Input
TESTHI11 P1 Power/Other Input
TESTHI12 W2 Power/Other Input
TESTHI13 L2 Asynch GTL+ Input
THERMDA AL1 Power/Other
THERMDC AK1 Power/Other
THERMTRIP# M2 Asynch GTL+ Output
TMS AC1 TAP Input
TRDY# E3 Common Clock Input
TRST# AG1 TAP Input
VCC AA8 Power/Other
VCC AB8 Power/Other
VCC AC23 Power/Other
VCC AC24 Power/Other
VCC AC25 Power/Other
Table 4-1. Alphabetical Land
Assignments
Land Name
Land
#
Signal Buffer
Type
Direction

Intel 520J - Pentium 4 2.80GHz 800MHz 1MB Socket 775 CPU Specifications

General

Clock Speed	2.80 GHz
Front Side Bus Speed	800 MHz
L2 Cache	1 MB
Socket Type	LGA 775
Core	Prescott
Lithography	90 nm
Thermal Design Power (TDP)	84 W
Instruction Set	x86
Virtualization Technology	No
64-bit Support	Yes
Hyper-Threading	Yes
Integrated Graphics	No
Processor Model	Intel Pentium 4 520J
Extensions	SSE2, SSE3
