Getting Started
16 Developer’s Kit User Manual
CRB Implementation Comments
1 internal port (supports USB flash)
SPI BIOS flash
Socketed, 8 Mb 8-pin socket
PCI Express*
1 PCIe* 1.1 X1 slot Non-standard location
PCI expansion
1 PCI 2.3 slot Un-populated (rework required)
Clocks
IDT* ICS9LPRS501 system clock
generator
CK-505 compatible
RTC
Battery-backed real time clock
Thermal
Monitoring
Processor temperature sensor
Processor Voltage
Regulator
Intel
®
Mobile Voltage Positioning
(Intel
®
MVP)-6 for processor core
Power Supply
12VDC +/-5% 2mm connector 12VDC, 5.0A, 60W
Debug Interfaces
Extended Debug Port (XDP) XDP connector
Power
Management
ACPI Compliant S0 – Power On
S3 – Suspend to RAM
S4 – Suspend to Disk
S5 – Soft Off
Form Factor
Mini-ITX
6.75” X 6.75” (17 cm X 17 cm)
Note: Review the document provided with the Development Kit titled “Important Safety and
Regulatory Information”. This document contains safety warnings and cautions that
must be observed when using this development kit.
2.3 Included Hardware and Documentation
This following hardware and documentation is included in the development kit:
• Intel
®
Atom™ Processor N270 and Mobile Intel
®
945GSE Express Chipset
Development Board (Installed)
• Firmware Hub (FWH) (Installed)
• Combination CPU/GMCH heatsink (Installed)
• Jumpers (Installed)
• 1 GB DDR2 SODIMM (Installed)
• Type 2032, socketed 3V lithium coin cell battery (Installed)
• Mini-ITX Chassis
• 12V AC-DC adapter with universal AC plugs
• SATA DVD-ROM Drive (Installed)
• 80 GB 2.5” SATA Mobile Hard Drive (Installed)
• Associated cables (Installed)
• Documentation and Software CD
