Intel Atom N270 - Led

Hardware Reference
Developer’s Kit User Manual 33
4.5 LED
Table 9 lists the LEDs that provide status of various functions on the CRB.
Table 9. CRB LEDs
Function Reference Designator
DCIN – RED D2
+5VA – RED D3
+5VS – YELLOW D4
+2.5S – GREEN D5
+3.3S – YELLOW D6
§
