Intel Core i7 Extreme Edition User Manual

Electrical Specifications
16 Datasheet
0 0 0 1 1 1 1 1 1.41875 0 1 1 1 1 0 1 0 0.85000
0 0 1 0 0 0 0 0 1.41250 0 1 1 1 1 0 1 1 0.84374
0 0 1 0 0 0 0 1 1.40625 0 1 1 1 1 1 0 0 0.83750
0 0 1 0 0 0 1 0 1.40000 0 1 1 1 1 1 0 1 0.83125
0 0 1 0 0 0 1 1 1.39375 0 1 1 1 1 1 1 0 0.82500
0 0 1 0 0 1 0 0 1.38750 0 1 1 1 1 1 1 1 0.81875
0 0 1 0 0 1 0 1 1.38125 1 0 0 0 0 0 0 0 0.81250
0 0 1 0 0 1 1 0 1.37500 1 0 0 0 0 0 0 1 0.80625
0 0 1 0 0 1 1 1 1.36875 1 0 0 0 0 0 1 0 0.80000
0 0 1 0 1 0 0 0 1.36250 1 0 0 0 0 0 1 1 0.79375
0 0 1 0 1 0 0 1 1.35625 1 0 0 0 0 1 0 0 0.78750
0 0 1 0 1 0 1 0 1.35000 1 0 0 0 0 1 0 1 0.78125
0 0 1 0 1 0 1 1 1.34375 1 0 0 0 0 1 1 0 0.77500
0 0 1 0 1 1 0 0 1.33750 1 0 0 0 0 1 1 1 0.76875
0 0 1 0 1 1 0 1 1.33125 1 0 0 0 1 0 0 0 0.76250
0 0 1 0 1 1 1 0 1.32500 1 0 0 0 1 0 0 1 0.75625
0 0 1 0 1 1 1 1 1.31875 1 0 0 0 1 0 1 0 0.75000
0 0 1 1 0 0 0 0 1.31250 1 0 0 0 1 0 1 1 0.74375
0 0 1 1 0 0 0 1 1.30625 1 0 0 0 1 1 0 0 0.73750
0 0 1 1 0 0 1 0 1.30000 1 0 0 0 1 1 0 1 0.73125
0 0 1 1 0 0 1 1 1.29375 1 0 0 0 1 1 1 0 0.72500
0 0 1 1 0 1 0 0 1.28750 1 0 0 0 1 1 1 1 0.71875
0 0 1 1 0 1 0 1 1.28125 1 0 0 1 0 0 0 0 0.71250
0 0 1 1 0 1 1 0 1.27500 1 0 0 1 0 0 0 1 0.70625
0 0 1 1 0 1 1 1 1.26875 1 0 0 1 0 0 1 0 0.70000
0 0 1 1 1 0 0 0 1.26250 1 0 0 1 0 0 1 1 0.69375
0 0 1 1 1 0 0 1 1.25625 1 0 0 1 0 1 0 0 0.68750
0 0 1 1 1 0 1 0 1.25000 1 0 0 1 0 1 0 1 0.68125
0 0 1 1 1 0 1 1 1.24375 1 0 0 1 0 1 1 0 0.67500
0 0 1 1 1 1 0 0 1.23750 1 0 0 1 0 1 1 1 0.66875
0 0 1 1 1 1 0 1 1.23125 1 0 0 1 1 0 0 0 0.66250
0 0 1 1 1 1 1 0 1.22500 1 0 0 1 1 0 0 1 0.65625
0 0 1 1 1 1 1 1 1.21875 1 0 0 1 1 0 1 0 0.65000
0 1 0 0 0 0 0 0 1.21250 1 0 0 1 1 0 1 1 0.64375
0 1 0 0 0 0 0 1 1.20625 1 0 0 1 1 1 0 0 0.63750
0 1 0 0 0 0 1 0 1.20000 1 0 0 1 1 1 0 1 0.63125
0 1 0 0 0 0 1 1 1.19375 1 0 0 1 1 1 1 0 0.62500
0 1 0 0 0 1 0 0 1.18750 1 0 0 1 1 1 1 1 0.61875
0 1 0 0 0 1 0 1 1.18125 1 0 1 0 0 0 0 0 0.61250
0 1 0 0 0 1 1 0 1.17500 1 0 1 0 0 0 0 1 0.60625
0 1 0 0 0 1 1 1 1.16875 1 0 1 0 0 0 1 0 0.60000
0 1 0 0 1 0 0 0 1.16250 1 0 1 0 0 0 1 1 0.59375
0 1 0 0 1 0 0 1 1.15625 1 0 1 0 0 1 0 0 0.58750
0 1 0 0 1 0 1 0 1.15000 1 0 1 0 0 1 0 1 0.58125
0 1 0 0 1 0 1 1 1.14375 1 0 1 0 0 1 1 0 0.57500
0 1 0 0 1 1 0 0 1.13750 1 0 1 0 0 1 1 1 0.56875
0 1 0 0 1 1 0 1 1.13125 1 0 1 0 1 0 0 0 0.56250
0 1 0 0 1 1 1 0 1.12500 1 0 1 0 1 0 0 1 0.55625
Table 2-1. Voltage Identification Definition (Sheet 2 of 3)
VID
7
VID
6
VID
5
VID
4
VID
3
VID
2
VID
1
VID
0
V
CC_MAX
VID
7
VID
6
VID
5
VID
4
VID
3
VID
2
VID
1
VID
0
V
CC_MAX

Intel Core i7 Extreme Edition Specifications

General

Socket	LGA 1366
TDP	130W
Max Memory Size	24 GB
PCI Express Version	2.0
Virtualization Technology	Yes
Hyper-Threading Technology	Yes
Turbo Boost Technology	Yes
Memory Types	DDR3-1066
