Land Listing
42 Datasheet
DDR2_MA[3] J20 CMOS O
DDR2_MA[4] F20 CMOS O
DDR2_MA[5] K23 CMOS O
DDR2_MA[6] K22 CMOS O
DDR2_MA[7] J24 CMOS O
DDR2_MA[8] L25 CMOS O
DDR2_MA[9] H22 CMOS O
DDR2_ODT[0] L16 CMOS O
DDR2_ODT[1] F13 CMOS O
DDR2_ODT[2] D15 CMOS O
DDR2_ODT[3] D10 CMOS O
DDR2_RAS# D17 CMOS O
DDR2_RESET# E32 CMOS O
DDR2_WE# C16 CMOS O
FC_AH5 AH5
ISENSE AK8 Analog I
PECI AH36 Asynch I/O
PRDY# B41 GTL O
PREQ# C42 GTL I
PROCHOT# AG35 GTL I/O
PSI# AP7 CMOS O
QPI_CLKRX_DN AR42 QPI I
QPI_CLKRX_DP AR41 QPI I
QPI_CLKTX_DN AF42 QPI O
QPI_CLKTX_DP AG42 QPI O
QPI_CMP[0] AL43 Analog
QPI_DRX_DN[0] AU37 QPI I
QPI_DRX_DN[1] AV38 QPI I
QPI_DRX_DN[10] AT42 QPI I
QPI_DRX_DN[11] AR43 QPI I
QPI_DRX_DN[12] AR40 QPI I
QPI_DRX_DN[13] AN42 QPI I
QPI_DRX_DN[14] AM43 QPI I
QPI_DRX_DN[15] AM40 QPI I
QPI_DRX_DN[16] AM41 QPI I
QPI_DRX_DN[17] AP40 QPI I
QPI_DRX_DN[18] AP39 QPI I
QPI_DRX_DN[19] AR38 QPI I
QPI_DRX_DN[2] AV37 QPI I
Table 4-1. Land Listing by Land Name
(Sheet 11 of 36)
Land Name
Land
No.
Buffer
Type
Direction
QPI_DRX_DN[3] AY36 QPI I
QPI_DRX_DN[4] BA37 QPI I
QPI_DRX_DN[5] AW38 QPI I
QPI_DRX_DN[6] AY38 QPI I
QPI_DRX_DN[7] AT39 QPI I
QPI_DRX_DN[8] AV40 QPI I
QPI_DRX_DN[9] AU41 QPI I
QPI_DRX_DP[0] AT37 QPI I
QPI_DRX_DP[1] AU38 QPI I
QPI_DRX_DP[10] AU42 QPI I
QPI_DRX_DP[11] AT43 QPI I
QPI_DRX_DP[12] AT40 QPI I
QPI_DRX_DP[13] AP42 QPI I
QPI_DRX_DP[14] AN43 QPI I
QPI_DRX_DP[15] AN40 QPI I
QPI_DRX_DP[16] AM42 QPI I
QPI_DRX_DP[17] AP41 QPI I
QPI_DRX_DP[18] AN39 QPI I
QPI_DRX_DP[19] AP38 QPI I
QPI_DRX_DP[2] AV36 QPI I
QPI_DRX_DP[3] AW36 QPI I
QPI_DRX_DP[4] BA36 QPI I
QPI_DRX_DP[5] AW37 QPI I
QPI_DRX_DP[6] BA38 QPI I
QPI_DRX_DP[7] AU39 QPI I
QPI_DRX_DP[8] AW40 QPI I
QPI_DRX_DP[9] AU40 QPI I
QPI_DTX_DN[0] AH38 QPI O
QPI_DTX_DN[1] AG39 QPI O
QPI_DTX_DN[10] AE43 QPI O
QPI_DTX_DN[11] AE41 QPI O
QPI_DTX_DN[12] AC42 QPI O
QPI_DTX_DN[13] AB43 QPI O
QPI_DTX_DN[14] AD39 QPI O
QPI_DTX_DN[15] AC40 QPI O
QPI_DTX_DN[16] AC38 QPI O
QPI_DTX_DN[17] AB38 QPI O
QPI_DTX_DN[18] AE38 QPI O
QPI_DTX_DN[19] AF40 QPI O
Table 4-1. Land Listing by Land Name
(Sheet 12 of 36)
Land Name
Land
No.
Buffer
Type
Direction

Intel Core i7 Extreme Edition Specifications

General

Socket	LGA 1366
TDP	130W
Max Memory Size	24 GB
PCI Express Version	2.0
Virtualization Technology	Yes
Hyper-Threading Technology	Yes
Turbo Boost Technology	Yes
Memory Types	DDR3-1066
