Intel Core i7 Extreme Edition User Manual

Land Listing
52 Datasheet
VSS AT23 GND
VSS AT26 GND
VSS AT29 GND
VSS AT32 GND
VSS AT35 GND
VSS AT38 GND
VSS AT41 GND
VSS AT7 GND
VSS AT8 GND
VSS AU1 GND
VSS AU11 GND
VSS AU14 GND
VSS AU17 GND
VSS AU20 GND
VSS AU22 GND
VSS AU23 GND
VSS AU26 GND
VSS AU29 GND
VSS AU32 GND
VSS AU35 GND
VSS AU36 GND
VSS AU43 GND
VSS AU5 GND
VSS AV11 GND
VSS AV14 GND
VSS AV17 GND
VSS AV20 GND
VSS AV22 GND
VSS AV23 GND
VSS AV26 GND
VSS AV29 GND
VSS AV32 GND
VSS AV39 GND
VSS AV4 GND
VSS AV41 GND
VSS AW1 GND
VSS AW11 GND
VSS AW14 GND
VSS AW17 GND
Table 4-1. Land Listing by Land Name
(Sheet 31 of 36)
Land Name
Land
No.
Buffer
Type
Direction
VSS AW20 GND
VSS AW22 GND
VSS AW23 GND
VSS AW26 GND
VSS AW29 GND
VSS AW32 GND
VSS AW35 GND
VSS AW6 GND
VSS AW8 GND
VSS AY11 GND
VSS AY14 GND
VSS AY17 GND
VSS AY2 GND
VSS AY20 GND
VSS AY22 GND
VSS AY23 GND
VSS AY26 GND
VSS AY29 GND
VSS AY32 GND
VSS AY37 GND
VSS AY42 GND
VSS AY7 GND
VSS B2 GND
VSS B37 GND
VSS B42 GND
VSS BA11 GND
VSS BA14 GND
VSS BA17 GND
VSS BA20 GND
VSS BA26 GND
VSS BA29 GND
VSS BA3 GND
VSS BA35 GND
VSS BA39 GND
VSS BA5 GND
VSS C35 GND
VSS C40 GND
VSS C43 GND
VSS C5 GND
Table 4-1. Land Listing by Land Name
(Sheet 32 of 36)
Land Name
Land
No.
Buffer
Type
Direction

Intel Core i7 Extreme Edition Specifications

General

Socket	LGA 1366
TDP	130W
Max Memory Size	24 GB
PCI Express Version	2.0
Virtualization Technology	Yes
Hyper-Threading Technology	Yes
Turbo Boost Technology	Yes
Memory Types	DDR3-1066
