Land Listing
54 Datasheet
VSS U7 GND
VSS V10 GND
VSS V35 GND
VSS V40 GND
VSS V5 GND
VSS W3 GND
VSS W38 GND
VSS W43 GND
VSS W8 GND
VSS Y1 GND
VSS Y11 GND
VSS Y33 GND
VSS Y36 GND
VSS Y41 GND
VSS Y6 GND
VSS_SENSE AR8 Analog
VSS_SENSE_VTT AE37 Analog
VTT_SENSE AE36 Analog
VTT_VID2 AV3 CMOS O
VTT_VID3 AF7 CMOS O
VTT_VID4 AV6 CMOS O
VTTA AD10 PWR
VTTA AE10 PWR
VTTA AE11 PWR
VTTA AE33 PWR
VTTA AF11 PWR
VTTA AF33 PWR
VTTA AF34 PWR
VTTA AG34 PWR
VTTD AA10 PWR
VTTD AA11 PWR
VTTD AA33 PWR
VTTD AB10 PWR
VTTD AB11 PWR
VTTD AB33 PWR
VTTD AB34 PWR
VTTD AB8 PWR
VTTD AB9 PWR
VTTD AC10 PWR
Table 4-1. Land Listing by Land Name
(Sheet 35 of 36)
Land Name
Land
No.
Buffer
Type
Direction
VTTD AC11 PWR
VTTD AC33 PWR
VTTD AC34 PWR
VTTD AC35 PWR
VTTD AD34 PWR
VTTD AD35 PWR
VTTD AD36 PWR
VTTD AD9 PWR
VTTD AE34 PWR
VTTD AE35 PWR
VTTD AE8 PWR
VTTD AE9 PWR
VTTD AF36 PWR
VTTD AF37 PWR
VTTD AF8 PWR
VTTD AF9 PWR
VTTPWRGOOD AB35 Asynch I
Table 4-1. Land Listing by Land Name
(Sheet 36 of 36)
Land Name
Land
No.
Buffer
Type
Direction

Intel Core i7 Extreme Edition Specifications

General

Socket	LGA 1366
TDP	130W
Max Memory Size	24 GB
PCI Express Version	2.0
Virtualization Technology	Yes
Hyper-Threading Technology	Yes
Turbo Boost Technology	Yes
Memory Types	DDR3-1066
