Intel D2500CC Product Guide

Intel Desktop Board D2500CC Product Guide
12
Table 2. Intel Desktop Board D2500CC Components
Label Description
A Back panel connectors
B Standby power indicator
C Main power connector (2 x 12 pin)
D Serial port header
E Processor
F SO-DIMM 0 slot
G SO-DIMM 1 slot
H TPM header
I Flat panel voltage selection header
J Backlight inverter voltage selection header
K Flat panel display brightness connector
L LVDS interface connector
M Intel NM10 Express Chipset
N System fan header
O SATA connectors
P Front panel header
Q S/PDIF out header
R Battery
S USB front panel header
T Front panel wireless activity LED header
U Serial port header
V BIOS configuration jumper block
W PCI Express Full-Mini Card slot
X PCI bus connector
Y Piezoelectric speaker
Z Parallel port header
AA Front panel audio header
BB USB front panel header with Intel Z-U130 USB Solid-State Drive (or
compatible device) support

Intel D2500CC Specifications

General

Brand	Intel
Model	D2500CC
Category	Motherboard
Language	English
