1 Desktop Board Features
This chapter briefly describes the main features of Intel
®
Desktop Board D2500CC.
Table 1 summarizes the features
of the Desktop Board.
Table 1. Feature Summary
Form Factor
Mini-ITX (170 millimeters [6.7 inches] x 170 millimeters [6.7 inches])
Processor
Passively-cooled, soldered-down dual-core Intel
®
Atom
™
processor with
integrated graphics and memory controller
Main Memory
• Two 204-pin Double Data Rate 3 (DDR3) Small Outline Dual Inline
Memory Module (SO-DIMM) sockets with gold-plated contacts
• Support for DDR3 1066/1333/1600 MHz SO-DIMMs
(DDR3 1333 MHz and DDR3 1600 MHz SO-DIMMs operate at
1066 MHz only)
• Support for up to 4 GB of system memory
Chipset
Intel
®
NM10 Express Chipset
Integrated
Graphics
Intel
®
Graphics Media Accelerator 3600 (Intel
®
GMA 3600) integrated
graphics subsystem with support for digital video (DVI-I), VGA, and
flat panel displays via an LVDS display interface
External Graphics
External graphics support provided through the PCI bus connector
Audio
RealTek* ALC662 audio codec for 5.1 (6-channel) Intel
®
High
Definition Audio (Intel
®
HD Audio) and AC ’97 Audio. Included are:
• Back panel audio connectors
• Onboard S/PDIF digital audio header
• Front panel microphone/headphone header with support for Intel HD
Audio or AC ’97 Audio
Legacy I/O
Legacy I/O Controller (Nuvoton* W83677HG-I) that provides:
• Four serial ports: two via onboard headers and two via back panel
connectors
• One parallel port via an onboard header
• Hardware management support
Expansion
Capabilities
• One PCI* bus add-in card connector
• One PCI Express* Full-Mini Card slot with Half-Mini Card support
Peripheral
Interfaces
• Seven USB 2.0 ports:
― Four back panel ports
― Three front panel ports (via two internal headers; a single-port
header supports an Intel
®
Z-U130 USB Solid-State Drive or
compatible device
• Two Serial ATA (SATA) 3.0 Gb/s interfaces
Hardware Monitor
Subsystem
Hardware monitoring through the Nuvoton* W83627DH-P legacy I/O
controller, including:
• Remote thermal sensor
• One 3-pin system fan header with speed control
continued
