Intel Desktop Board D2500CC Product Guide
14
Graphics Support
Integrated Graphics Subsystem
The Intel GMA 3600 integrated graphics subsystem features the following:
• 400 MHz core frequency
• High quality texture engine
⎯ DX10.1c* and OpenGL* 3.0 compliant
⎯ Hardware Pixel Shader 4.1
⎯ Vertex Shader Model 4.1
• Video
⎯ J.264 and VC1 hardware decoder
⎯ HDCP 1.3
• Displays
⎯ VGA
⎯ Digital Visual Interface (DVI-I)
⎯ Flat Panel Display
VGA
The Desktop Board supports analog displays with a back-panel VGA port.
The maximum supported resolution is 1920 x 1200 at a 60 Hz refresh rate.
Digital Visual Interface
The Desktop Board supports Digital Visual Interface (DVI) displays with a back-panel
DVI-I port. The DVI-I port is compliant with the DVI 1.0 specification.
The maximum supported digital display resolution is 1900 x 1200 at a 60 Hz refresh
rate.
Flat Panel Display
The board supports flat panel displays based on the LVDS interface. Support is
provided by the following connectors and headers:
• LVDS interface connector
• Flat panel voltage selection header
• Flat panel display brightness connector
• Backlight inverter voltage selection header
The connectors and headers are shown in Figure 2.
For more i
nformation on flat panel display support, refer to the Intel Desktop Board
D2500CC Technical Product Specification located at
http://www.intel.com/products/motherboard/index.htm
.
