Installing and Replacing Desktop Board Components
37
S/PDIF Header
Figure 12, H shows the location of the S/PDIF output header. Table 13 shows the pin
assignments for the header.
Table 13. S/PDIF Header
Pin Signal Name
1 Ground
2 S/PDIF
3 Key (no pin)
4 + 5 VDC
Front Panel Wireless Activity LED Header
Before connecting to the front panel wireless activity LED header, observe the
precautions in "Before You Begin" on page 23. See Figure 12, I for the location of the
front
panel wireless activity LED header.
Table 14 shows the pin assignments for the front panel wireless activity LED header.
Table 14. Front Panel Wireless Activity LED Header
Pin Signal Name
1 Ground
2 MINICARD_WLAN#
