Installing and Replacing Desktop Board Components
39
Connecting to a Power Supply
CAUTION
Failure to connect an appropriate power su
p
ply to the De
sktop Board may result
in
damage to the board or the sys
tem may not functio
n properly.
Figure 14 shows t
he location
of the power connector.
Figure 14. Connectin
g Power Supply C
ables
1.
Observe the
precautions in "
Before You Begin" on page
23.
2.
Connect
the main power suppl
y cable to the 2 x 12 pi
n connector.
38
40
