Intel Desktop Board D2500CC Technical Product Specification
14
Table 3. Board Components Shown in Figure 1
Item/callout
from Figure 1
Description
A
Back panel connectors
B
Standby power LED
C
Processor core power connector (2 x 12)
D
Serial port header
E
Intel Atom processor
F
SO-DIMM channel A DIMM 0 socket
G
SO-DIMM channel A DIMM 1 socket
H
Trusted Platform Module (TPM) header
I
Backlight inverter voltage selection jumper
J
Flat panel voltage selection jumper
K
FPD brightness connector
L
LVDS data connector
M
Intel NM10 Express Chipset
N
System fan header
O
SATA connectors
P
Front panel header
Q S/PDIF header
R Battery
S
Front panel USB 2.0 header
T
Front Panel Wireless Activity LED header
U
Serial port header
V BIOS setup configuration jumper block
W
PCI Express Full-/Half-Mini Card slot
X
Conventional PCI bus add-in card connector
Y
Piezoelectric speaker
Z
Parallel port header
AA
Front panel audio header
BB
Front panel USB header with Intel Z-U130 USB Solid-State
Drive or compatible device support (brown-colored)
