Intel Desktop Board D2500CC Technical Product Specification
44
Table 11 lists the component-side connectors and headers identified in Figure 11.
Table 11. Component-side Connectors and Headers Shown in Figure 11
Item/callout
from Figure 11 Description
A
Processor core power connector (2 x 12)
B
Serial port header
C
TPM header
D
Backlight inverter voltage selection jumper
E
Flat panel voltage selection jumper
F
FPD brightness connector
G
LVDS data connector
H
System fan header
I
SATA connector
J
SATA connector
K
Front panel header
L
S/PDIF header
M Front panel USB 2.0 header
N Front Panel Wireless Activity LED header
O Serial port header
P
PCI Express Full-/Half-Mini Card slot
Q
Conventional PCI bus add-in card connector
R
Parallel port header
S
Front panel audio header
T
Front panel USB header with Intel Z-U130 USB Solid-State Drive or compatible
device support (brown-colored)
